Volvo EC290B(SER NO INT 13562- EU & NA 80001-) SA9452-05209 Hose assembly wholesale
Part Name: SA9452-05209 Hose assembly
KDSORT: 460, 170, 370, 510
UE: U
ANT1: 1, 0000
ANT2: 1
ANT3: 0000
Hose Recipe Asmoverall Length MM: 450
Hose Recipe Asmoverall Length Inch: 17.72
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 19
Hose Part Hose Size Inch: 3/4"
Hose Part Hose Dash: -12
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 26
Hose Part Hose Outer Diameter INCH: 1.02
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 56122/914/400, 56126/911/400, 20078/914/500, 56139/914/500, 56120/911/400, 56135/911/400
Looking for Part NO.SA9452-05209?
We offer CUMMINS / ISUZU / SUMITOMO / Deutz / YANMAR / SAMSUNG aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9452-05209 Rockmaster/1SC suitable for 1005431 Hydraulic system, hydraulic tank to hydraulic oil cooler assembly.
Volvo SA9452-05209(c.1005431) Rockmaster/1SC
Ref: 1005431 / 35 / 1
SA8277406 / P / EW130 Basic Machine
56135/911/400
Volvo SA9452-05209 Hose assembly suitable for 1008102 Hydraulic system, hydraulic tank to hydraulic oil cooler assembly.
Volvo SA9452-05209(c.1008102) Rockmaster/1SC
Ref: 1008102 / 36 / 1
56120/911/400
Volvo SA9452-05209 Rockmaster/1SC suitable for 1004625 Hydraulic system, hydraulic tank to hydraulic oil cooler assembly.
Volvo SA9452-05209(c.1004625) Rockmaster/1SC
Ref: 1004625 / 8 / 1
56126/911/400
Volvo SA9452-05209 Hose assembly suitable for 1006713 Servo system, pump piping and filter mount. assembly.
Volvo SA9452-05209(c.1006713) Rockmaster/1SC
Ref: 1006713 / 24 / 1
VOE8277459 / P / EC290B Basic Machine
56139/914/500
Volvo SA9452-05209 Rockmaster/1SC suitable for 1022551 Servo system, pump piping and filter mount. assembly.
Volvo SA9452-05209(c.1022551) Rockmaster/1SC
Ref: 1022551 / 24 / 1
VOE8280312 / U / EC290B Basic Machine
VOE8277459 / P / EC290B Basic Machine
20078/914/500
VOLVO Parts for sale offer HYUNDAI / Kubota / SAMSUNG / CUMMINS / MITSUBISHI / CASE spare parts. MOQ 1 pcs is available! Volvo Part NO.SA9452-05209 is on sale now!
Part NO. SA9452-05209 for Volvo EW130
This catalogue lists the spare parts for Excavator EW130
BASIC MACHINE
PROD NO 8277406 EW130
ENGINE
Part No. 1111-00103 Type, B 5,9 - C
Part NO. SA9452-05209 for Volvo EC360
This catalogue lists the spare parts for Excavator EC360
BUCKETS
Bucket GP. ESCO. 1,35/1,5 - F24
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
1,35 = Volume CECE cubic meter.
1,5 = Volume SAE cubic meter.
S3 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR x 50
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
50 = Number of track shoes
Part NO. SA9452-05209 for Volvo EC290B
This catalogue lists the spare parts for Excavator EC290B
BASIC MACHINE
PROD NO 8277459, EC290B, KOR S/N 10001 - 13561
PROD NO 8277459, EC290B, CHN S/N 30001 -
ENGINE
Part No. 14500386, D7D EAE2, S/N 10001-10972
Part No. 14500386, D7D EAE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EPA
Part No. 14519199, D7D ECE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EU
Part No. 14519200, D7D EDE2, KOR S/N 10973- / CHN S/N 30007-
Without label
Part NO. SA9452-05209 for Volvo EC150
EXCAVATOR VOLVO EC150
BASIC MACHINE
PROD NO DK00A001 EC150
ENGINE
Part No. 14504020 Typ, 4BTA3.9-C for Low-Emission
Part NO. SA9452-05209 for Volvo EC290B(SER NO INT 13562- EU & NA 80001-)
This catalogue lists the spare parts for Excavator EC290B
BASIC MACHINE
PROD NO 8277459, EC290B, SER NO ; KOR 10001 - 16792
PROD NO 8277459, EC290B, SER NO ; CHN 30001 - 31086
PROD NO 8279533, EC290B, SER NO ; EU and NA 80001 - 81230
PROD NO 8280312, EC290B, SER NO ; INT and KOR 13562 - 16792, 30224 - 31086
ENGINE
Part No. 14500386, D7D EAE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EPA
Part No. 14519199, D7D ECE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EU
Part No. 14519200, D7D EDE2, KOR S/N 10973- / CHN S/N 30007-
Without label
Part No. 14527732, D7E EAE3, S/N 80001- Emission Certificated from EPA/EU
Part NO. SA9452-05209 for Volvo EC140
This catalogue lists the spare parts for Excavator EC140
BUCKETS
Bucket GP. ESCO. 0,32/0,35 - F24
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
0,32 = Volume CECE cubic meter.
0,35 = Volume SAE cubic meter.
S6 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR X 42LCM, 600SR X 46LC
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
42 = Number of track shoes
