China Made VOE15676984 Eternity/2 parts for Volvo Excavator

Volvo-VOE15676984-on-sale

View

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo excavator spare part VOE15676984 Eternity/2

Part Name: VOE15676984 Hose assembly
KDSORT: 530, 280, 491
UE: U
ANT1: 1
GLB_ANM1: S/N 5603-5605. 5610-, S/N 5784-5785, 5788-
Hose Recipe Asmoverall Length MM: 2850
Hose Recipe Asmoverall Length Inch: 112.20
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Protector Length MM: 1300
Hose Recipe Protector Length INCH: 51.18
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 21
Hose Part Hose Outer Diameter INCH: 0.83
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20133/916/360, 20134/916/350, 20133/916/350

Looking for Part NO.VOE15676984?
We supply Kubota / MITSUBISHI / HYUNDAI / Deutz / Caterpillar / SUMITOMO spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

VOE15676984 for Volvo Hydraulic circuit ( platform/balancing valve/offset cylinder )(1048600 assembly)

Volvo VOE15676984 Hose assembly suitable for 1048600 Hydraulic circuit ( platform/balancing valve/offset cylinder ) assembly.

Volvo VOE15676984(c.1048600) Hose assembly
Ref: 1048600 / 29 / 1
20134/916/350

VOE15676984 for Volvo Hydraulic circuit ( platform/balancing valve/offset cylinder )(1076758 assembly)

Volvo VOE15676984 Hose assembly suitable for 1076758 Hydraulic circuit ( platform/balancing valve/offset cylinder ) assembly.

Volvo VOE15676984(c.1076758) Hose assembly
Ref: 1076758 / 16 / 1
VOE11839908 / P / EC35C Excavator
20133/916/360

VOE15676984 for Volvo Hydraulic circuit ( platform/balancing valve/offset cylinder )(1027767 assembly)

Volvo VOE15676984 Eternity/2 suitable for 1027767 Hydraulic circuit ( platform/balancing valve/offset cylinder ) assembly.

Volvo VOE15676984(c.1027767) Eternity/2
Ref: 1027767 / 29 / 1
20133/916/350

VOLVO Aftermarket offer Kobelco / SAMSUNG / ISUZU / Hitachi / MITSUBISHI / KATO spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE15676984 is on sale now!

Part NO. VOE15676984 for Volvo EC35C
EXCAVATOR VOLVO EC35C
BASIC MACHINE
PROD NO 11839908, S/N 3538 -
ENGINE
Part No. 11806938, S/N - 4104
Part No. 11808572, S/N 4105 -

Part NO. VOE15676984 for Volvo ECR48C
EXCAVATOR VOLVO ECR48C
BASIC MACHINE
PROD NO. 11839909, S/N 4838 -
ENGINE
Part No. 11806938, S/N - 5175
Part No. 11808572, S/N 5176 -
