Volvo ECR58D(S/N 210001-, 280001-) excavator spare part VOE936398 Hose assembly
Part Name: VOE936398 Hose assembly
KDSORT: 340, 190, 150
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 550
Hose Recipe Asmoverall Length Inch: 21.65
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 36.5
Hose Part Hose Pressure Class PSI: 5293
Hose Part Hose Pressure Class BAR: 365
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 17
Hose Part Hose Outer Diameter INCH: 0.67
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20783/522/325, 20669/916/5000, 20669/916/4900
Looking for Part NO.VOE936398?
We supply YANMAR / Kobelco / Komatsu / KATO / CUMMINS / ISUZU aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE936398 Hose assembly suitable for 1050964 Working hydraulics, dozer blade upper assembly.
Volvo VOE936398(c.1050964) Hose assembly
Ref: 1050964 / 10 / 1
VOE8291746 / U / WITH FLOATING Dozer blade
20669/916/5000
Volvo VOE936398 Hose assembly suitable for 1069330 Working hydraulics, dozer blade upper assembly.
Volvo VOE936398(c.1069330) Hose assembly
Ref: 1069330 / 13 / 1
VOE8291746 / U / WITH FLOATING Dozer blade
VOE8291747 / U / W/O FLOATING Dozer blade
20669/916/4900
Volvo VOE936398 Hose assembly suitable for 1090602 Brake lines, trailer assembly.
Volvo VOE936398(c.1090602) Eternity/2
Ref: 1090602 / 6 / 1
VOE37706 / P / A60H Articulated hauler
20783/522/325
We supply KATO / MITSUBISHI / CUMMINS / Kobelco / ISUZU / YANMAR aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE936398 is on sale now!
Part NO. VOE936398 for Volvo ECR58D(S/N 210001-, 280001-)
EXCAVATOR VOLVO ECR58D
BASIC MACHINE
PROD NO 8291695, S/N 210001-, 280001-
SUB BASIC MACHINE
PROD NO 8291696, S/N 280001-
PROD NO 8291697, S/N 210001-
CAB
PROD NO. 8291703
PROD NO. 8291704
PROD NO. 8293428
PROD NO. 8293429
PROD NO. 8293430
PROD NO. 8293431
ENGINE
Part no. 14617296, D2.6A
Part no. 14649076, D2.6A
Part no. 14617294, D2.6H
Part NO. VOE936398 for Volvo A60H
ARTICULATED HAULER VOLVO A60H
BASIC MACHINE
Product number 37706 BRA, Serial number 320001-
Product number 37706 BRA, Serial number 340001-
Product number 37706 BRA, Serial number 350001-
CAB
Product number 11294124
DRIVE AXLES
Product number 56082, AHW80
Product number 56083, AHW80
Product number 56084, AHW80
HYDRAULIC TRANSMISSION
Product number 22702, ALLISON 6630 ORS
DROPBOX
Product number 22594, IL3
ENGINE
Product number, 17479230, D16J
Replacement version, 17510362
Product number, 15185584, D16J
Replacement version, 17451253
Product number, 15185585, D16J
Replacement version, 17451254
Product number, 15185582, D16F
Replacement version, 17451233
Product number, 17479231, D16J
Replacement version, 17510368
