Hose assembly VOE937752 for Volvo excavator EC460CHR(HIGH REACH DEMOLITION) excavator
Part Name: VOE937752 Hose assembly
KDSORT: 340, 420, 8008, 190, 230
UE: U
ANT1: 1
ANT2: 1, 0000
ANT3: 1
Hose Recipe Asmoverall Length MM: 1450
Hose Recipe Asmoverall Length Inch: 57.09
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 25
Hose Part Hose Size Inch: 1"
Hose Part Hose Dash: -16
Hose Part Hose Pressure Class MPA: 11.0
Hose Part Hose Pressure Class PSI: 1595
Hose Part Hose Pressure Class BAR: 110
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 34
Hose Part Hose Outer Diameter INCH: 1.34
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20100/924/1000, 20434/914/3600, 20228/914/2600, 20888/916/4060, 20228/914/3600, 20102/924/1000, 20101/924/1010
Looking for Part NO.VOE937752?
We offer Komatsu / Doosan / SUMITOMO / Caterpillar / Deutz / Hitachi spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE937752 Rockmaster/1SC suitable for 1025708 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE937752(c.1025708) Rockmaster/1SC
Ref: 1025708 / 29 / 1
VOE8285674(VOE14592467) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8285673(VOE14592466) / U / ON/OFF Leak-off line for slope-rotator on basic machine
20100/924/1000, 20101/924/1010
Volvo VOE937752 Rockmaster/1SC suitable for 1048759 Working hydraulic, adjustable boom for upper assembly.
Volvo VOE937752(c.1048759) Rockmaster/1SC
Ref: 1048759 / 14 / 1
VOE8288953 / P / EC460CHR Basic Machine
20228/914/3600
Volvo VOE937752 Hose assembly suitable for 1025581 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE937752(c.1025581) Hose assembly
Ref: 1025581 / 22 / 1
VOE8280288(VOE14564602) / U / ON/OFF CONTROL Leak-off line for slope-rotator on basic machine
VOE8280090(VOE14564604) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
20102/924/1000
Volvo VOE937752 Hose assembly suitable for 1100057 Working hydraulic, clamshell assembly.
Volvo VOE937752(c.1100057) Hose assembly
Ref: 1100057 / 9 / 1
VOE8301776 / U / 2.9 M Grapple manoeuvre. Leak-off line on dip. arm
20888/916/4060
Volvo VOE937752 Rockmaster/1SC suitable for 1029962 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo VOE937752(c.1029962) Rockmaster/1SC
Ref: 1029962 / 10 / 1
VOE8288953 / P / EC460CHR Basic Machine
20228/914/2600
Heavy Volvo supply ISUZU / Kubota / CUMMINS / Kobelco / SUMITOMO / KATO aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE937752 is on sale now!
Part VOE937752 suitable for:
VOE8286692(VOE14602762) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8286690 / U / WITHOUT Leak-off line for slope-rotator on basic machine
VOE8286691(VOE14602761) / U / ON/OFF Leak-off line for slope-rotator on basic machine
Part NO. VOE937752 for Volvo EC460C
This catalogue lists the spare parts for Excavator EC460C.
BASIC MACHINE
PROD NO. 8280026, EC460C, SER NO ; 110001 -
ENGINE
Part No. 8188764, D12D : Emission-certified from EPA and EU
Part NO. VOE937752 for Volvo EC360C
This catalogue lists the spare parts for Excavator EC360C
BASIC MACHINE
PROD NO 8280830, EC360C, S/N 110001 - 115000 KOR
PROD NO 8280830, EC360C, S/N 140001 - 145000 USA
ENGINE
Part No. 8188768, D12DEBE3, S/N - 110411 KOR;
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, S/N 110412 - 110481 KOR, 8280231
Part No. 8188756, D12D-H, S/N 140012 - 140044 USA, 8280231
Part No. 8188757, D12D-P, S/N 110482 - KOR, 8280231
Part No. 8188757, D12D-P, S/N 140045 - USA, 8280231
Part NO. VOE937752 for Volvo EC200E(S/N 310011-)
EXCAVATOR VOLVO EC200E
BASIC MACHINE
Product number 8301794, Serial number 310011-
CAB
Product number 8292998
Product number 8294134
Product number 8295278
Product number 8295279
Product number 8300787
Product number 8300788
Product number 8300789
Product number 8300790
ENGINE
Product number 16064173, D4 T4F US
Product number 16064174, D4 T4F EU
Part NO. VOE937752 for Volvo EC460C(S/N 115001-115434)
This catalogue lists spare parts for Excavator EC460C.
BASIC MACHINE
PROD NO. 8280026, EC460C, S/N 115001 - 115434
ENGINE
Part No. 8188757, D12D-P, 8286626,
Emission-certified from EPA and EU
Part NO. VOE937752 for Volvo EC460CHR(HIGH REACH DEMOLITION)
This catalogue lists spare parts for Excavator EC460CHR.
BASIC MACHINE
PROD NO. 8288953, EC460CHR, S/N 190001 - 190022
ENGINE
Part No. 8188757, D12D-P, S/N 110364 - , 8288626,
Emission-certified from EPA and EU
Part NO. VOE937752 for Volvo EC330C(S/N 110001 - 110158, 140001 - 140055)
This catalog lists the spare parts for Excavator EC330C
BASIC MACHINE
PROD NO. 8281065, EC330C, S/N 110001 - 110158 KOR
PROD NO. 8281065, EC330C, S/N 140001 - 140055 USA
ENGINE
Part No. 8188768, D12DEBE3, 8280231
S/N - 110052 KOR;
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, 8280231
S/N 110053 - 110064 KOR,
S/N 140001 - 140005 USA
Part No. 8188757, D12D-P, 8280231
S/N 110065 - KOR,
S/N 140006 - USA
