Hose assembly VOE937991 for Volvo excavator ECR145D(S/N 210001-210766) excavator
Part Name: VOE937991 Hose assembly
KDSORT: 190, 490, 540, 130, 151, 240, 280, 200, 140, 110, 210, 510, 530
UE: U
ANT1: 1
ANT2: 1
ANT3: 1
ANT4: 1
GLB_ANM1: L = 900 MM, S/N -310447, S/N 310699-, S/N 311692-, S/N -311198
Hose Recipe Asmoverall Length MM: 900
Hose Recipe Asmoverall Length Inch: 35.43
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 25
Hose Part Hose Size Inch: 1"
Hose Part Hose Dash: -16
Hose Part Hose Pressure Class MPA: 11.0
Hose Part Hose Pressure Class PSI: 1595
Hose Part Hose Pressure Class BAR: 110
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 34
Hose Part Hose Outer Diameter INCH: 1.34
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20229/911/410, 20229/914/500, 20740/924/1000, 20140/914/500, 20140/911/400, 20229/914/510, 20141/924/1000, 20715/911/440, 20730/924/2400, 20138/924/1000, 20687/911/250, 20633/924/1000, 20740/924/1100, 20641/924/1000
Looking for Part NO.VOE937991?
We supply Caterpillar / Hitachi / Deutz / Doosan / SUMITOMO / HYUNDAI spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE937991 Rockmaster/1SC suitable for 1025641 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE937991(c.1025641) Hose assembly
Ref: 1025641 / 4 / 1
VOE8282294(VOE14574444) / U / ON/OFF Leak-off line for slope-rotator on basic machine
VOE8282295(VOE14574445) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
20138/924/1000
Volvo VOE937991 Hose assembly suitable for 1089495 Servo system, pump piping and filter mount. assembly.
Volvo VOE937991(c.1089495) Rockmaster/1SC
Ref: 1089495 / 10 / 1
VOE8292961 / U Swing drive
20229/914/510
Volvo VOE937991 Hose assembly suitable for 1079426 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE937991(c.1079426) Hose assembly
Ref: 1079426 / 27 / 1
VOE8297225 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8297224 / U / ON/OFF_40LPM Leak-off line for slope-rotator on basic machine
VOE8295489 / U / PROPORTIONAL CONTROL, 60LPM Leak-off line for slope-rotator on basic machine
VOE8297226 / U / ON/OFF_60LPM Leak-off line for slope-rotator on basic machine
20730/924/2400, 20730/924/2410
Volvo VOE937991 Hose assembly suitable for 1025698 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE937991(c.1025698) Hose assembly
Ref: 1025698 / 12 / 2
VOE8283024 / U / WITHOUT Leak-off line for slope-rotator on basic machine
VOE8283025(VOE14579623) / U / ON/OFF Leak-off line for slope-rotator on basic machine
VOE8283026(VOE14579624) / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
20141/924/1000
Volvo VOE937991 Hose assembly suitable for 1080862 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE937991(c.1080862) Rockmaster/1SC
Ref: 1080862 / 7 / 1
VOE8296301 / U / PROP_60LPM Leak-off line for slope-rotator on basic machine
VOE8298187(VOE14701134) / U / ON/OFF_ 60LPM Leak-off line for slope-rotator on basic machine
VOE8298186 / U / ON/OFF 40LPM Leak-off line for slope-rotator on basic machine
20740/924/1100, 20740/924/1000
VOLVO Parts for sale supply ISUZU / Deutz / CASE / YANMAR / KATO / Kobelco spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE937991 is on sale now!
Part VOE937991 suitable for:
VOE8291691 / U Leak-off line for slope-rotator on basic machine
VOE8281800 / U Boom - None
VOE8290301 / U Leak-off line for slope-rotator on basic machine
VOE8291692 / U Leak-off line for slope-rotator on basic machine
VOE8292784 / P / EC700CHR Basic Machine
VOE8292961 / U Swing drive
VOE8292219 / U Swing drive
VOE8282430 / P / EC700C Basic Machine
VOE8292220 / U Swing drive
VOE8290141 / U / PROPORTIONAL CONTROL, 60 LPM Leak-off line for slope-rotator on basic machine
VOE8291237 / U / ON/OFF, 60 LPM Leak-off line for slope-rotator on basic machine
VOE8281800 / U Boom - None
VOE8291236 / U / ON/OFF, 40 LPM Leak-off line for slope-rotator on basic machine
VOE8294566 / U / W/O HRV Float position for boom
Part NO. VOE937991 for Volvo EC140C(S/N 110001-111312)
This catalogue lists the spare parts for Excavator EC140C.
BASIC MACHINE
PROD NO. 8282939, EC140C, SER NO ; 110001 - 111312
ENGINE
Part No. 14536072, D4E EBE3 : Emission-certified from EPA and EU
Part NO. VOE937991 for Volvo ECR145E(S/N 310001-)
EXCAVATOR VOLVO ECR145E
BASIC MACHINE
Product number 8296283, Serial number 310001-
CAB
Product number 8295958
Product number 8297796
Product number 8297797
Product number 8297798
Product number 8301655
Product number 8301656
Product number 8301657
Product number 8301658
ENGINE
Product number 17229198, D4 T4f
Product number 17229196, D4 T4f
Product number 17480990, D4 T4f
Product number 17506991, D4J T4f
Product number 17668804, D4 STAGE V
Part NO. VOE937991 for Volvo EC700C(S/N 110001-110770)
This catalogue lists the spare parts for Excavator EC700C.
BASIC MACHINE
PROD NO. 8282430, EC700C, SER NO 110001 - 110770
ENGINE
Part No. 8188183, D16EEAE3, S/N - 110032, Emission-certified from EPA and EU
Part No. 8188186, D16E-A, S/N 110033 - 110770
Part NO. VOE937991 for Volvo EC350E(S/N 310001-)
EXCAVATOR VOLVO EC350E
BASIC MACHINE
Product number 8296122, Serial number 310001-
CAB
Product number 8293303
Product number 8293304
Product number 8295011
Product number 8295012
Product number 8302044
Product number 8302046
Product number 8302050
Product number 8302052
ENGINE
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product number 17479201
Replacement version 17510356
Part NO. VOE937991 for Volvo EC380E(S/N 310001-)
EXCAVATOR VOLVO EC380E
BASIC MACHINE
Product no. 8293277, S/N 310001-
CAB
Product no. 8293303
Product no. 8293304
Product no. 8295011
Product no. 8295012
Product no. 8295391
Product no. 8302183
Product no. 8302044
Product no. 8302046
Product no. 8302050
Product no. 8302052
ENGINE
Product no. 15185568
Replacement version 17272079
Product no. 15185569
Replacement version 17272080
Product no. 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359
Part NO. VOE937991 for Volvo ECR145D(S/N 210001-210766)
EXCAVATOR VOLVO ECR145D
BASIC MACHINE
PROD NO. 8290284, S/N 210001- 210766
CAB
PART NO. 8290225, 8291326
ENGINE
PART NO. 15165683, D4, EU
part not stocked as spare part
PART NO. 17231751, replacement version
PART NO. 15083702, D4, US
part not stocked as spare part
PART NO. 17231719, replacement version
