PJ5471042 Pilot for Volvo Excavator spare

VOLVO-PJ5471042-wholesale

View

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo EC250E(S/N 310001-, 320001-) Hose assembly Part NO. PJ5471042

Part Name: PJ5471042 Hose assembly
KDSORT: 240, 370, 770, 490, 120, 130, 170, 190, 110, 160, 140, 380, 290, 150
UE: U
ANT1: 1
ANT2: 0000, 1
ANT3: 0000, 1
INFLYTT: 1
GLB_ANM1: 1/4"
Hose Recipe Asmoverall Length MM: 2300
Hose Recipe Asmoverall Length Inch: 90.55
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Pilot
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: Volvo 100
Hose Part Hose Standard SAE: Volvo 100
Hose Part Hose Standard EN: Volvo 100
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Extreme lightness
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20138/914/3000, 20670/914/3000, 20730/914/300, 20743/916/550, 20725/914/2450, 20888/914/2700, 20097/914/2000, 20629/914/350, 20888/914/2400, 20668/914/110, 20712/914/2600, 20888/914/2650, 10005/912/360, 20615/914/2480

Looking for Part NO.PJ5471042(VOE936975)?
We supply ISUZU / SUMITOMO / HYUNDAI / Komatsu / Doosan / YANMAR spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.

VOE936975 replacement for new Part NO.PJ5471042

PJ5471042 for Volvo Servo system, control valve to solenoid valve(1025394 assembly)

Volvo PJ5471042 Pilot suitable for 1025394 Servo system, control valve to solenoid valve assembly.

Volvo PJ5471042(c.1025394) Hose assembly
Ref: 1025394 / 4 / 1
VOE8282199 / U Float position for boom
VOE8280864 / U Float position for boom
20100/914/2000, 20101/914/2000

PJ5471042 for Volvo Servo system, control valve to solenoid valve(1079570 assembly)

Volvo PJ5471042 Pilot suitable for 1079570 Servo system, control valve to solenoid valve assembly.

Volvo PJ5471042(c.1079570) Pilot
Ref: 1079570 / 9 / 1
VOE8295493 / U / W/HRV Float position for boom
20730/914/350

PJ5471042 for Volvo Hydraulic circuit ( safety valve / dipper arm )(9164NY1 assembly)

Volvo PJ5471042 Pilot suitable for 9164NY1 Hydraulic circuit ( safety valve / dipper arm ) assembly.

Volvo PJ5471042(c.9164NY1) Hose assembly
Ref: 9164NY1 / 5 / 1
10005/912/360, 10006/912/360, 10007/912/360, 10008/912/360

PJ5471042 for Volvo Servo system, dozer blade(1080176 assembly)

Volvo PJ5471042 Hose assembly suitable for 1080176 Servo system, dozer blade assembly.

Volvo PJ5471042(c.1080176) Hose assembly
Ref: 1080176 / 4 / 1
VOE8297806 / U / WITH DOZER BLADE 700MM Lower frame, bolted step
VOE8299970 / U / WITH DOZER BLADE, 600MM Lower frame, welded step
VOE8299971 / U / WITH DOZER BLADE, 700MM Lower frame, welded step
VOE8295967 / U / WITH DOZER BLADE 600MM Lower frame, bolted step
VOE8297807 / U / WITH DOZER BLADE 800MM Lower frame, bolted step
20739/914/3000, 20739/914/3100

PJ5471042 for Volvo Servo system, hammer and shear(1075008 assembly)

Volvo PJ5471042 Hose assembly suitable for 1075008 Servo system, hammer and shear assembly.

Volvo PJ5471042(c.1075008) Hose assembly
Ref: 1075008 / 11 / 1
VOE8295408 / U / DOUBLE ACTING FOR PRESET Hydr. leak-off line for hammer-shear. 1 pump
VOE8295295 / U / DOUBLE ACTING FOR PRESET Hydr. leak-off line for hammer-shear. 1 pump
20714/914/2450, 20712/914/2450

Heavy Volvo offer CASE / Kobelco / CUMMINS / HYUNDAI / SUMITOMO / Hitachi aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.PJ5471042(VOE936975) is on sale now!

Part PJ5471042 suitable for:
VOE8291986 / P / EC80D Basic Machine
VOE8297235 / U / W/O HRV Float position for boom
VOE8291986 / P / EC80D Basic Machine
VOE8299295 / P / T2 Basic Machine
VOE8301288 / U Leak-off line for slope-rotator on basic machine
VOE8300560 / U Leak-off line for slope-rotator on basic machine
VOE8291674 / U / WITH DOZER BLADE AND 500MM SHOE Lower frame, bolted step
VOE8291675 / U / WITH DOZER BLADE AND 700MM SHOE Lower frame, bolted step
VOE8290292 / U / WITH DOZER BLADE AND 600MM SHOE Lower frame, bolted step
VOE8282243 / U / WITH DOZER BLADE AND 500MM SHOE Lower frame, bolted step
VOE8283916 / U / WITH DOZER BLADE AND 600MM SHOE Lower frame, bolted step
VOE8282409 / U / WITH DOZER BLADE AND 700MM SHOE Lower frame, bolted step

Part NO. PJ5471042 for Volvo EC210C
This catalogue lists the spare parts for Excavator EC210C.
BASIC MACHINE
PROD NO 8279769, EC210C, KOR SER NO ; 110001 - 112052
PROD NO 8279769, EC210C, KONZ SER NO ; 120001 - 122073
PROD NO 8279769, EC210C, USA SER NO ; 140001 - 140246
ENGINE
Part No. 14527730, D6E EAE3. Emission Certificated from EPA and EU
Part No. 14545980, D6E EFE3, Emission Certificated from EPA and EU

Part NO. PJ5471042 for Volvo EC30(TYPE 282)
EXCAVATOR VOLVO EC30
BASIC MACHINE
282.10151 EC30
ENGINE
Part No. VOE 11804244 Typ, S3L2-63ES
Part No. VOE 11806067 Typ, S3L2-W263ES

Part NO. PJ5471042 for Volvo ECR145C(S/N 110001-)
This catalogue lists the spare parts for Excavator ECR145C.
BASIC MACHINE
PROD NO 8282208, ECR145C, SER NO ; 110001 -
ENGINE
Part No. : 14533106, D4E EAE3 Emission Certified from EPA/EU

Part NO. PJ5471042 for Volvo FC2421C(S/N 110001-110078)
This catalogue lists the spare parts for Excavator FC2421C.
BASIC MACHINE
PROD NO 8284052, FC2421C, S/N 110001-110078
ENGINE
Part No. 14527730, D6E EAE3. Emission Certified from EPA and EU

Part NO. PJ5471042 for Volvo EC140E(S/N 310001-)
EXCAVATOR VOLVO EC140E
BASIC MACHINE
Product number 8295469, Serial number 310001-
CAB
Product number 8297212
Product number 8297213
Product number 8297211
Product number 8295481
Product number 8297214
Product number 8300791
Product number 8301651
Product number 8301652
Product number 8301653
Product number 8301654
ENGINE
Replacement version 17506989
Replacement version 17668802
Replacement version 17229187
Replacement version 17229186

Part NO. PJ5471042 for Volvo ECR88D(S/N 210001-215000)
EXCAVATOR VOLVO ECR88D
BASIC MACHINE
PROD NO 8291417, S/N 210001- 215000
CAB
PROD NO. 8291430
PROD NO. 8293042
ENGINE
Part no. 14617298, 8291418
Part no. 14646505, 8293037

We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).

Original PJ5471042(VOE936975) included regular invoice.
Used/Second hand PJ5471042 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
