Volvo EC360B(PRIME S/N 15001-/85001- 35001-) excavator spare part SA9451-05218 Hose assembly
Part Name: SA9451-05218 Hose assembly
KDSORT: 290, 150, 430, 490, 470, 110, 410, 320
UE: U
ANT1: 1
ANT2: 1
ANT3: 1
Hose Recipe Asmoverall Length MM: 900
Hose Recipe Asmoverall Length Inch: 35.43
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 19
Hose Part Hose Size Inch: 3/4"
Hose Part Hose Dash: -12
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 26
Hose Part Hose Outer Diameter INCH: 1.02
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 56122/914/200, 20076/914/500, 56138/914/500, 56138/914/550, 20077/914/500, 20668/911/510, 20668/911/520, 20488/914/500, 56137/914/500, 56137/914/550, 20489/914/500
Looking for Part NO.SA9451-05218?
We supply MITSUBISHI / Kubota / KATO / CASE / CUMMINS / YANMAR spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9451-05218 Hose assembly suitable for 1011970 Servo system, pump piping and filter mount. assembly.
Volvo SA9451-05218(c.1011970) Hose assembly
Ref: 1011970 / 28 / 2
VOE8279093 / P / EC360B WITH D10 ENGINE Basic Machine
VOE8277279 / P / EC360B Basic Machine
VOE8279094 / P / EC330B WITH D10 ENGINE Basic Machine
VOE8277717 / P / EC330B Basic Machine
56137/914/500, 56138/914/500
Volvo SA9451-05218 Hose assembly suitable for 1022555 Servo system, control valve to solenoid valve assembly.
Volvo SA9451-05218(c.1022555) Rockmaster/1SC
Ref: 1022555 / 19 / 1
VOE8279095 / P / EC360B WITH D12 ENGINE Basic Machine
56137/914/550
Volvo SA9451-05218 Hose assembly suitable for 1048612 Servo system, pump piping and filter mount. assembly.
Volvo SA9451-05218(c.1048612) Rockmaster/1SC
Ref: 1048612 / 34 / 1
VOE8289533 / U Swing drive
VOE8277279 / P / EC360B Basic Machine
VOE8292413 / U Swing drive
VOE8280270 / P / EC330B Basic Machine
VOE8277717 / P / EC330B Basic Machine
20488/914/500, 20489/914/500
Volvo SA9451-05218 Rockmaster/1SC suitable for 1034471 Servo system, control valve to solenoid valve assembly.
Volvo SA9451-05218(c.1034471) Rockmaster/1SC
Ref: 1034471 / 2 / 1
VOE8280230 / P / D12D Basic Machine
VOE8277279 / P / EC360B Basic Machine
VOE8280270 / P / EC330B Basic Machine
VOE8277717 / P / EC330B Basic Machine
20076/914/500, 20077/914/500
Volvo SA9451-05218 Rockmaster/1SC suitable for 1022553 Servo system, control valve to solenoid valve assembly.
Volvo SA9451-05218(c.1022553) Hose assembly
Ref: 1022553 / 19 / 1
VOE8279096 / P / EC330B WITH D12 ENGINE Basic Machine
56138/914/550
We offer Komatsu / Deutz / CUMMINS / MITSUBISHI / YANMAR / HYUNDAI spare parts. MOQ 1 pcs is available! Volvo Part NO.SA9451-05218 is on sale now!
Part SA9451-05218 suitable for:
VOE8299295 / P / T2 Basic Machine
VOE8291986 / P / EC80D Basic Machine
Part NO. SA9451-05218 for Volvo EC360B(SER NO INT 12152-13919 EU&NA 80001-81037)
This catalog lists the spare parts for Excavator EC360B
BASIC MACHINE
PROD NO 8277279, EC360B
PROD NO 8280230, EC360B, SER NO ; EU and NA 80001 - 85000
PROD NO 8279095, EC360B, SER NO ; INT 12152 - 15000
PROD NO 8279095, EC360B, SER NO ; CHN 30001 - 35000
ENGINE
Part No. 8188768, D12D EBE3, S/N - 80992 KOR ; Emission Certificated from EPA and EU
Part No. 8188756, D12D-H, S/N 80993 - 81015 KOR, 8280231
Part No. 8188757, D12D-P, S/N 81016 - KOR, 8280231
Part No. 8188758, D12D EBE2, S/N - 13100 KOR, 8280232 ; Without label
Part No. 8188746, D12D-G, S/N 13101 - 13248 KOR, 8280232
Part No. 8188747, D12D-O, S/N 13249 - KOR, 8280232
Part No. 8188747, D12D-O, S/N 130001 - CHN, 8280232
Part NO. SA9451-05218 for Volvo EC330B
This catalog lists the spare parts for Excavator EC330B
BASIC MACHINE
PROD NO 8277717, EC330B
PROD NO 8279094, EC330B D10B ENGINE ; SER NO 10212-10235
PROD NO 8279096, EC330B D12C ENGINE ; SER NO 10236-10712
ENGINE
Part No. 8188147, D10B EAE2 ; SER NO 10001-10134
Without label
Part No. 8188147, D10B EAE2 ; SER NO 10135-10235
Part No. 8188176, D12C ECE2 ; SER NO 10236-
Emission Certificated from EPA
Part No. 8188154, D10B EBE2 ; SER NO 10135-10235
Part No. 8188177, D12C EDE2 ; SER NO 10236-
Emission Certificated from EU
Part No. 8188155, D10B ECE2 ; SER NO 10135-10235
Part No. 8188178, D12C EEE2 ; SER NO 10236-
Without label
Part NO. SA9451-05218 for Volvo EC360
This catalogue lists the spare parts for Excavator EC360
BUCKETS
Bucket GP. ESCO. 1,35/1,5 - F24
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
1,35 = Volume CECE cubic meter.
1,5 = Volume SAE cubic meter.
S3 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR x 50
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
50 = Number of track shoes
Part NO. SA9451-05218 for Volvo EC80D(S/N 210001-210013 230001-230916, 232001-)
EXCAVATOR VOLVO EC80D
BASIC MACHINE
Product number 8291986, Serial number 210001-210013, 230001-230916, 232001-
SUB BASIC MACHINE
Product number 8297429, Serial number 232001-
Product number 8299295, Serial number 232001-
CAB
Product number 8291996
Product number 8291997
Product number 8291998
Product number 8292024
Product number 8297439
Product number 8297440
Product number 8297437
Product number 8297438
ENGINE
Product number 14575308, T2
Product number 17317553, T3
Part NO. SA9451-05218 for Volvo EC330B(PRIME S/N 15001-15582)
This catalog lists the spare parts for Excavator EC330B
BASIC MACHINE
PROD NO 8277717, EC330B, S/N 15001- 15582
ENGINE
Part No. 8188757, D12D-P, 8288738
Emission Certificated from EPA and EU
Part No. 8188747, D12D-O, 8288736
Part NO. SA9451-05218 for Volvo EC330B(S/N INT 10713-10806 EU&NA 80001-80425)
This catalog lists the spare parts for Excavator EC330B
BASIC MACHINE
PROD NO 8277717, EC330B
PROD NO 8280270, EC330B, SER NO EU and NA 80001 - 80425
PROD NO 8279096, EC330B, SER NO INT 10713 - 10806
ENGINE
Part No. 8188768, D12D EBE3, S/N - 80425 KOR, 8280231,
Emission Certificated from EPA and EU
Part No. 8188756, D12D-H, 8280231
Part No. 8188757, D12D-P, S/N 80426 - KOR, 8280231
Part No. 8188758, D12D EBE2, S/N - 10783 KOR, 8280232,
without EPA label
Part No. 8188746, D12D-G, S/N 10784 KOR, 8280232
Part No. 8188747, D12D-O, S/N 10785 - KOR, 8280232
