Volvo EC210B(PRIME S/N 35-,40-,50-, 70-,80-,81-,90-,95-95057) SA9452-03232 Hose assembly wholesale
Part Name: SA9452-03232 Hose assembly
KDSORT: 330, 310, 200, 150
UE: U
ANT1: 2
GLB_ANM1: SER NO 70264-
GLB_ANM2: SER NO 80036-
Hose Recipe Asmoverall Length MM: 1600
Hose Recipe Asmoverall Length Inch: 62.99
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 22.5
Hose Part Hose Pressure Class PSI: 3263
Hose Part Hose Pressure Class BAR: 225
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 16
Hose Part Hose Outer Diameter INCH: 0.63
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20460/914/100, 20463/914/100, 20431/914/100, 20601/914/100
Looking for Part NO.SA9452-03232?
We supply YANMAR / Hitachi / SUMITOMO / Komatsu / HYUNDAI / KATO aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9452-03232 Rockmaster/1SC suitable for 1096732 Servo system, control valve to remote control valve assembly.
Volvo SA9452-03232(c.1096732) Rockmaster/1SC
Ref: 1096732 / 20 / 2
VOE8289339 / U / WITHOUT Float position for boom
VOE8286029 / P / EC290B Basic Machine
20431/914/100
Volvo SA9452-03232 Hose assembly suitable for 1044523 Servo system, control valve to remote control valve assembly.
Volvo SA9452-03232(c.1044523) Hose assembly
Ref: 1044523 / / 2
VOE8289465 / P / 2700 UPPER Basic Machine
VOE8289500 / U Leak-off line for slope-rotator on basic machine
VOE8286123 / U / 2700MM Upper frame
20460/914/100
Volvo SA9452-03232 Hose assembly suitable for 1070459 Servo system, control valve to remote control valve assembly.
Volvo SA9452-03232(c.1070459) Rockmaster/1SC
Ref: 1070459 / 6 / 2
VOE8290308 / P / EC200B Basic Machine
20601/914/100
Volvo SA9452-03232 Rockmaster/1SC suitable for 1045663 Servo system, control valve to remote control valve assembly.
Volvo SA9452-03232(c.1045663) Rockmaster/1SC
Ref: 1045663 / 19 / 2
VOE8287964 / P / EC240B Basic Machine
20463/914/100
We supply Komatsu / Caterpillar / Kobelco / KATO / CUMMINS / Kubota spare parts. MOQ 1 pcs is available! VOLVO Part NO.SA9452-03232 is on sale now!
Part NO. SA9452-03232 for Volvo EC290B(PRIME S/N 17001-/50001- 35001-35895 / 85001-86284)
This catalogue lists the spare parts for Excavator EC290B
BASIC MACHINE
PROD NO 8277459, EC290B, KOR S/N 17001-, 85001 - 86284
PROD NO 8277459, EC290B, CHN S/N 35001 - 35895
PROD NO 8277459, EC290B, INDIA S/N 50001- 50154
ENGINE
Part No. 14536078, D7D, Emission Certificated from EPA and EU
Part No. 14536075, D7D, Without label
Part NO. SA9452-03232 for Volvo EC200B(PRIME S/N 30001-31313)
This catalogue lists the spare parts for Excavator EC200B.
BASIC MACHINE
PROD NO 8290308, EC200B, CHN S/N 30001 - 31313
ENGINE
Part No. 14536073, D6D, Without label
Part NO. SA9452-03232 for Volvo EC210B(PRIME S/N 35-,40-,50-, 70-,80-,81-,90-,95-95057)
This catalogue lists the spare parts for Excavator EC210B.
BASIC MACHINE
PROD NO 8277784, EC210B, CHN S/N 35001 - 39999
PROD NO 8277784, EC210B, CHN S/N 90001 - 92051
PROD NO 8277784, EC210B, CHN S/N 95001 - 95057
PROD NO 8277784, EC210B, BRA S/N 40001 - 41093
PROD NO 8277784, EC210B, IND S/N 50001 - 52370
PROD NO 8277784, EC210B, KOR S/N 70001 - 79999
PROD NO 8277784, EC210B, KOR S/N 80001 - 80188
PROD NO 8277784, EC210B, KOR S/N 81001 -
ENGINE
Part No. 14536076, D6E EAE3, Emission Certificated from EPA and EU
Part No. 14536073, D6E EAE2, Without label
Part NO. SA9452-03232 for Volvo EC240B(PRIME S/N 15001-16436/ 40001-40237/ 35001-37526)
This catalogue lists the spare parts for Excavator EC240B.
BASIC MACHINE
PROD NO 8277587, EC240B, SER NO ; KOR 15001- 16436
PROD NO 8277587, EC240B, SER NO ; CHN 35001- 37526
PROD NO 8277587, EC240B, SER NO ; BRA 040001- 40237
ENGINE
Part No. : 14536074, D7E EBE2, Without label
