Volvo ECR38(TYPE 602) excavator spare part VOE11803596 Eternity/2
Part Name: VOE11803596 Hose assembly
KDSORT: 280, 270
UE: U
ANT1: 1
GLB_ANM1: L = 675mm/26.5748in
Hose Recipe Asmoverall Length MM: 675
Hose Recipe Asmoverall Length Inch: 26.57
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Protector Length MM: 600
Hose Recipe Protector Length INCH: 23.62
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 16
Hose Part Hose Size Inch: 5/8"
Hose Part Hose Dash: -10
Hose Part Hose Pressure Class MPA: 30.0
Hose Part Hose Pressure Class PSI: 4350
Hose Part Hose Pressure Class BAR: 300
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 25
Hose Part Hose Outer Diameter INCH: 0.98
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20048/916/2000, 20048/916/3000
Looking for Part NO.VOE11803596?
We offer CASE / SUMITOMO / HYUNDAI / Deutz / Kubota / Kobelco aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE11803596 Hose assembly suitable for 1074963 Hydr. circuit. ( attachment ) ( grab jaw ) assembly.
Volvo VOE11803596(c.1074963) Eternity/2
Ref: 1074963 / 14 / 1
20048/916/3000
Volvo VOE11803596 Hose assembly suitable for 1074962 Hydraulic circuit ( double-acting ) assembly.
Volvo VOE11803596(c.1074962) Eternity/2
Ref: 1074962 / 14 / 1
20048/916/2000
VOLVO Heavy Construction Equipment supply YANMAR / KATO / Caterpillar / SUMITOMO / Kobelco / Deutz aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE11803596 is on sale now!
Part NO. VOE11803596 for Volvo ECR38(TYPE 602)
EXCAVATOR VOLVO ECR38
BASIC MACHINE
602.10151 ECR38
ENGINE
Part No. VOE 11801176 Typ, D1.6C / D1.6A, S/N - 11342
Part No. VOE 15602421 Typ, D1,6DCAE3, S/N 11343 -
