Volvo Rockmaster/12 Part NO. VOE14372161
Part Name: VOE14372161 Hydraulic hose
KDSORT: 250, 190, 110
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1250
Hose Recipe Asmoverall Length Inch: 49.21
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 3
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/12
Hose Part Hose Size DN: 25
Hose Part Hose Size Inch: 1"
Hose Part Hose Dash: -16
Hose Part Hose Pressure Class MPA: 28.0
Hose Part Hose Pressure Class PSI: 4060
Hose Part Hose Pressure Class BAR: 280
Hose Part Hose Standard ISO: ISO 3862 R12
Hose Part Hose Standard SAE: SAE 100R12
Hose Part Hose Standard EN: EN 856 R12
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 38
Hose Part Hose Outer Diameter INCH: 1.50
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 99530/916/975, 99531/916/975, 20012/916/975, 20026/916/975, 99530/916/925, 20012/916/925, 99536/916/975
Looking for Part NO.VOE14372161?
We offer ISUZU / SUMITOMO / Komatsu / Deutz / Caterpillar / CASE aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE14372161 Rockmaster/12 suitable for 1008905 Hammer hydraulics mono boom, return line, offset assembly.
Volvo VOE14372161(c.1008905) Hydraulic hose
Ref: 1008905 / 2 / 1
VOE14303066(VOE11707939) / U Return oil line boom 4.7m, for hammer hydraulics
99530/916/975, 99536/916/975, 99531/916/975
Volvo VOE14372161 Hydraulic hose suitable for 1015258 Hammer hydraulics on adjustable boom, return line assembly.
Volvo VOE14372161(c.1015258) Hydraulic hose
Ref: 1015258 / 16 / 1
VOE14313105 / U Return oil line on 2pcs-off-set boom
20012/916/925
Volvo VOE14372161 Hydraulic hose suitable for 1013059 Hammer hydraulics mono boom, return line, offset assembly.
Volvo VOE14372161(c.1013059) Hydraulic hose
Ref: 1013059 / 2 / 1
VOE14313104 / U Return oil line boom 4.7m, for hammer hydraulics
VOE14314052 / U Return oil line boom 4.7m, for hammer hydraulics
20012/916/975, 20026/916/975
Volvo VOE14372161 Rockmaster/12 suitable for 1009394 Hammer hydraulics on adjustable boom, return line assembly.
Volvo VOE14372161(c.1009394) Rockmaster/12
Ref: 1009394 / 10 / 1
VOE14225111 / U Return oil line on 2pcs-off-set boom
99530/916/925
We supply CUMMINS / SUMITOMO / MITSUBISHI / Kubota / KATO / Doosan spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE14372161 is on sale now!
Part NO. VOE14372161 for Volvo EC160(SER NO 1001-)
EXCAVATOR VOLVO EC160
BASIC MACHINE
PROD NO 14301063 EC160 CHN, SER NO 1001 - 1059
PROD NO 14301064 EC160 CHW, SER NO 1001 - 1113
CAB
PROD NO 14371423
ENGINE
Part No. 14371017 Type TD 40 GHE, 14301063 = SER NO - 1021
Part No. 14371017 Type TD 40 GHE, 14301064 = SER NO - 1047
Part No. 14370943 Type TD 40 KGE, 14301063 = SER NO 1022 - 1049
Part No. 14370943 Type TD 40 KGE, 14301064 = SER NO 1048 - 1095
Part No. 14373449 Type TD 40 KGE, 14301063 = SER NO 1050 -
Part No. 14373449 Type TD 40 KGE, 14301064 = SER NO 1096 -
Part NO. VOE14372161 for Volvo EW140(SER NO 1001-1487)
EXCAVATOR VOLVO EW140
BASIC MACHINE
PROD NO 14301062 EW140, SER NO 1001 - 1487
CAB
PROD NO 14371423
ENGINE
Part No. 14371017 Type TD 40 GHE. SER NO - 1362
Part No. 14373450 Type TD 40 GHE. SER NO 1363 -
Part NO. VOE14372161 for Volvo EW140B
EXCAVATOR VOLVO EW140B
BASIC MACHINE
PROD NO 14311003, EW140B, S/N 8711001-8711983
CAB
PROD NO 14375945
ENGINE
Part No. 14380002, Type Volvo Cologne D5DEBE2
Part NO. VOE14372161 for Volvo EW160B
EXCAVATOR VOLVO EW160B
BASIC MACHINE
PROD NO 14311002, EW160B, S/N 8731001- 8732850
CAB
PROD NO 14375945
ENGINE
Part No. 14377064, Type D6DECE2
Part NO. VOE14372161 for Volvo EW160(SER NO 1001-1912)
EXCAVATOR VOLVO EW160
BASIC MACHINE
PROD NO 14301065 EW160, SER NO 1001 - 1912
CAB
PROD NO 14371423
ENGINE
Part No. 14370943 Type TD 40 KGE. SER NO - 1742
Part No. 14373449 Type TD 40 KGE. SER NO 1743 -
