VOE14596920 Hose for Volvo Excavator Parts
VOE14596920 Hose for Volvo Excavator Parts

VOE14596920 Hose for Volvo Excavator Parts

VOLVO-VOE14596920-in-stock

View

View

VOE14596920 Hose for Volvo Excavator Parts

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo EC360CHR(HIGH REACH DEMOLITION) excavator spare part VOE14596920 Hose

Part Name: VOE14596920 Hose
KDSORT: 100
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1580
Hose Recipe Asmoverall Length Inch: 62.20
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Protector Length MM: 1410
Hose Recipe Protector Length INCH: 55.51
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Xtraflex/5000
Hose Part Hose Size DN: 25
Hose Part Hose Size Inch: 1"
Hose Part Hose Dash: -16
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 18752-C
Hose Part Hose Standard SAE: Volvo 106
Hose Part Hose Standard EN: Volvo 106
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Extreme flexibility
Hose Part Hose Outer Diameter MM: 39
Hose Part Hose Outer Diameter INCH: 1.54
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20227/911/5500, 20656/911/5500
Looking for Part NO.VOE14596920?
We offer KATO / YANMAR / HYUNDAI / Deutz / Doosan / Kobelco aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE14596920 for Volvo Hydraulic system, intermediate arm piping(1077418 assembly)
Volvo VOE14596920 Hose suitable for 1077418 Hydraulic system, intermediate arm piping assembly.
Volvo VOE14596920(c.1077418) Hose
Ref: 1077418 / 1 / 1
VOE8292497 / P / EC380D HR Basic Machine
20656/911/5500
VOE14596920 for Volvo Hydraulic system, intermediate arm piping(1049245 assembly)
Volvo VOE14596920 Hose suitable for 1049245 Hydraulic system, intermediate arm piping assembly.
Volvo VOE14596920(c.1049245) Hose
Ref: 1049245 / 1 / 1
VOE8287522 / P / EC360CHR Basic Machine
20227/911/5500
We offer KATO / MITSUBISHI / Doosan / Caterpillar / Kobelco / Hitachi aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE14596920 is on sale now!
Part NO. VOE14596920 for Volvo EC360CHR(HIGH REACH DEMOLITION)
This catalogue lists spare parts for Excavator EC360CHR.
BASIC MACHINE
PROD NO 8287522, EC360CHR, S/N 190001-190016
ENGINE
Part No. 8188757, D12D-P, 8285527,
Emission-certified from EPA and EU
Part NO. VOE14596920 for Volvo EC380DHR(HIGH REACH DEMOLITION S/N 290011-290020,291001-)
EXCAVATOR VOLVO EC380D HR
BASIC MACHINE
PROD NO. 8292497 S/N 290001- 290020
CAB
PROD NO. 8292276
PROD NO. 8292275
ENGINE
D13H-D, EU
Product No. 15117871
Replacement version 15173113
D13H-C, US
Product No. 15049436
Replacement version 15173113
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original VOE14596920 included regular invoice.
Used/Second hand VOE14596920 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
