VOE14634376 Shieldmaster/5000 for Volvo Excavator Parts
VOE14634376 Shieldmaster/5000 for Volvo Excavator Parts
VOE14634376 Shieldmaster/5000 for Volvo Excavator Parts

VOE14634376 Shieldmaster/5000 for Volvo Excavator Parts

VOLVO-VOE14634376-for-sale

View

View

VOE14634376 Shieldmaster/5000 for Volvo Excavator Parts

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo ECR88D(S/N 210001-215000) VOE14634376 Hose wholesale

Part Name: VOE14634376 Hose
KDSORT: 121, 120, 100
UE: U
ANT1: 2
ANT2: 2
ANT3: 2
Hose Recipe Asmoverall Length MM: 2270
Hose Recipe Asmoverall Length Inch: 89.37
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Protector Length MM: 2270
Hose Recipe Protector Length INCH: 89.37
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Shieldmaster/5000
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 34.5
Hose Part Hose Pressure Class PSI: 5003
Hose Part Hose Pressure Class BAR: 345
Hose Part Hose Standard ISO: Volvo 104
Hose Part Hose Standard SAE: Volvo 104
Hose Part Hose Standard EN: Volvo 104
Hose Part Hose Standard MSHA: _
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: Outstanding abrasion resistance
Hose Part Hose Outer Diameter MM: 22
Hose Part Hose Outer Diameter INCH: 0.87
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20670/916/1000, 20885/916/8170, 20885/916/1050
Looking for Part NO.VOE14634376?
We offer SAMSUNG / Komatsu / ISUZU / KATO / Kubota / CUMMINS aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE14634376 for Volvo Working hydraulic, bucket cylinder on dipper arm(1098610 assembly)
Volvo VOE14634376 Hose suitable for 1098610 Working hydraulic, bucket cylinder on dipper arm assembly.
Volvo VOE14634376(c.1098610) Hose
Ref: 1098610 / 3 / 2
VOE8293071 / U / 2,1M Leak-off line on dip. arm without leak. for grapp.
20885/916/1050
VOE14634376 for Volvo Working hydraulic, bucket cylinder on dipper arm(1069838 assembly)
Volvo VOE14634376 Shieldmaster/5000 suitable for 1069838 Working hydraulic, bucket cylinder on dipper arm assembly.
Volvo VOE14634376(c.1069838) Shieldmaster/5000
Ref: 1069838 / 3 / 4
VOE8293071 / U / 2,1M Leak-off line on dip. arm without leak. for grapp.
VOE8294855 / U / LONG Dipper arm
VOE8291468 / U / 1,7M Leak-off line on dip. arm without leak. for grapp.
20670/916/1000
VOE14634376 for Volvo Working hydraulics, grab system on work equipment(1098710 assembly)
Volvo VOE14634376 Shieldmaster/5000 suitable for 1098710 Working hydraulics, grab system on work equipment assembly.
Volvo VOE14634376(c.1098710) Shieldmaster/5000
Ref: 1098710 / 1 / 2
VOE8303326 / U / LONG ARM W/O GRAPPLE PIPING Dipper arm
20885/916/8170
VOLVO Construction parts offer KATO / Caterpillar / Kubota / Komatsu / CASE / Kobelco aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE14634376 is on sale now!
Part NO. VOE14634376 for Volvo ECR88D(S/N 210001-215000)
EXCAVATOR VOLVO ECR88D
BASIC MACHINE
PROD NO 8291417, S/N 210001- 215000
CAB
PROD NO. 8291430
PROD NO. 8293042
ENGINE
Part no. 14617298, 8291418
Part no. 14646505, 8293037
Part NO. VOE14634376 for Volvo ECR88D(S/N 215001-)
EXCAVATOR VOLVO ECR88D
BASIC MACHINE
Product number 8291417, Serial number 215001-
SUB BASIC MACHINE
Product number 8301494, Serial number 215001-
CAB
Product number 8301525
Product number 8302204
Product number 8302205
ENGINE
Part number 17500660, D2.6H ST V, 8301495
Part number 17500656, D2.6H T4F, 8302201
VOLVO Parts for sale have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original VOE14634376 included regular invoice.
Used/Second hand VOE14634376 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
