Volvo EC300D(S/N 21/23/231001-/25/ 26/27/28000-) VOE14880647 Rockmaster/1SC wholesale
Part Name: VOE14880647 Hose assembly
KDSORT: 680, 310, 480, 100, 750, 400, 320, 470, 550, 200, 140, 410, 440, 350
UE: U
ANT1: 1, 2
ANT2: 1, 2, 0000
ANT3: 0000, 2, 1
ANT4: 0000, 1
ANT5: 1
GLB_ANM1: S/N -230035, S/N 120001-120678, S/N 120679-, S/N 120001-120240, S/N 120241-, S/N 120001-120700, S/N 120701-, S/N 120001-120238, S/N 120239-, S/N 120001-120676, S/N 120677-, S/N 120001-120244, S/N 120245-, S/N 111050-, SER NO 20604-, SER NO 6553-, SER NO 5442-
Hose Recipe Asmoverall Length MM: 700
Hose Recipe Asmoverall Length Inch: 27.56
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 26.0
Hose Part Hose Pressure Class PSI: 3770
Hose Part Hose Pressure Class BAR: 260
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20634/975/1000, 20731/975/800, 20887/911/5650, 56141/975/500, 20629/975/1100, 20631/975/550, 20714/975/700, 20615/975/1700, 20718/911/5650, 56139/975/500, 20078/975/500, 20098/975/500, 20099/975/500, 20095/975/600
Looking for Part NO.VOE14880647(SA9482-02114)?
We supply Hitachi / CASE / ISUZU / HYUNDAI / SUMITOMO / Kubota aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
SA9482-02114 replacement for new Part NO.VOE14880647
Volvo VOE14880647 Hose assembly suitable for 1017586 Dipper arm and grease piping with piping seat assembly.
Volvo VOE14880647(c.1017586) Hose assembly
Ref: 1017586 / 23 / 1
VOE8277531 / U / 3,05m Hd Dipper arm with leak seat
VOE8277532 / U / 4,0m Dipper arm with leak seat
VOE8279078 / U / 3,05M Hd Dipper arm with leak seat
VOE8277529 / U / 2,55m Dipper arm with leak seat
VOE8277530 / U / 3,05m Dipper arm with leak seat
VOE8278132 / U / 3,05m Long last bushing Hd Dipper arm with leak seat
VOE8278134 / U / 4,0m Long last bushing Dipper arm with leak seat
VOE8278130 / U / 3,05m Long last bushing Dipper arm with leak seat
VOE8278128 / U / 2,55m Long last bushing Dipper arm with leak seat
20078/975/550, 20078/975/650, 56139/975/550, 56139/975/650
Volvo VOE14880647 Hose assembly suitable for 1080170 Grease Piping assembly.
Volvo VOE14880647(c.1080170) Rockmaster/1SC
Ref: 1080170 / 16 / 1
VOE8297752 / U / 2.5M W/STRIP, N-BUSH Hd Dipper arm with leak seat
20739/975/600
Volvo VOE14880647 Rockmaster/1SC suitable for 1049871 Dipper arm and grease piping with piping seat assembly.
Volvo VOE14880647(c.1049871) Hose assembly
Ref: 1049871 / 18 / 1
VOE8291049 / U / 3M, N-BUSH, GP Dipper arm with leak seat
VOE8289925 / U / 3M, N-BUSH. GP Dipper arm with leak seat
20726/975/620, 20726/975/600
Volvo VOE14880647 Hose assembly suitable for 1049828 Dipper arm and grease piping with piping seat assembly.
Volvo VOE14880647(c.1049828) Hose assembly
Ref: 1049828 / 27 / 1
VOE8297752 / U / 2.5M W/STRIP, N-BUSH Hd Dipper arm with leak seat
20725/975/1100, 20763/975/1500, 20888/975/100
Volvo VOE14880647 Rockmaster/1SC suitable for 1076698 Hydraulic system, cab tilt assembly.
Volvo VOE14880647(c.1076698) Hose assembly
Ref: 1076698 / 1 / 2
VOE8297379 / U Tilting cab operating system
VOE8296963 / U Tilting cab operating system
VOE8301808 / U Tilting cab operating system
20719/911/5650, 20718/911/5650, 20887/911/5650
We supply Kobelco / SAMSUNG / ISUZU / Caterpillar / Hitachi / CASE spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE14880647(SA9482-02114) is on sale now!
Part VOE14880647 suitable for:
VOE8289924 / U / 2,6M, N-BUSH, GP Dipper arm with leak seat
VOE8291044 / U / 2,6M, N-BUSH, GP Dipper arm with leak seat
VOE8294486 / U / 2.6M, N-BUSH, HD Dipper arm with leak seat
VOE8281811 / U / 3,0M Dipper arm with leak seat
VOE8281810 / U / 2,6M Dipper arm with leak seat
VOE8281809 / U / 2,3M WITH STRIP Dipper arm with leak seat
VOE8280375 / U / 2,3M Dipper arm with leak seat
VOE8280377 / U / 3,0M WITH STRIP Dipper arm with leak seat
VOE8280376 / U / 2,6M WITH STRIP Dipper arm with leak seat
VOE8283103 / U / 3,0M LONG LAST BUSHING WITH STRIP Dipper arm with leak seat
VOE8283099 / U / 2,6M LONG LAST BUSHING WITH STRIP Dipper arm with leak seat
VOE8283093 / U / 2,3M LONG LAST BUSHING Dipper arm with leak seat
VOE8283095 / U / 2,3M LONG LAST BUSHING WITH STRIP Dipper arm with leak seat
VOE8283101 / U / 3.0M LONG LAST BUSHING Dipper arm with leak seat
VOE8283097 / U / 2,6M LONG LAST BUSHING Dipper arm with leak seat
VOE8291049 / U / 3M, N-BUSH, GP Dipper arm with leak seat
VOE8289925 / U / 3M, N-BUSH. GP Dipper arm with leak seat
VOE8294484 / U / 2.3M, N-BUSH, HD Dipper arm with leak seat
VOE8291041 / U / DIPPER ARM 2,3M Dipper arm with leak seat
Part NO. VOE14880647 for Volvo EC480EHR(S/N 390001-)
EXCAVATOR VOLVO EC480EHR
BASIC MACHINE
Product number 8297366, Serial number 390001-
CAB
Product number 8297057
Product number 8297058
ENGINE
Product number 15185568
Replacement version 17272079
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359
Part NO. VOE14880647 for Volvo EC300D(S/N 21/23/231001-/25/ 26/27/28000-)
EXCAVATOR VOLVO EC300D
BASIC MACHINE
PROD NO. 8289044, S/N 210001-211176, 230001-230373, 231001-, 250001-, 260001-260064, 270001-, 280001-
SUB BASIC MACHINE
PROD NO. 8292889 Waste handler, S/N 210044-
PROD NO. 8292890 Demolition, S/N 210068-
PROD NO. 8291941, S/N 210525-
PROD NO. 8292870, S/N 230001-230373, 231001-, 250001-, 260001-260064, 270001-, 280001-
PROD NO. 8301347, S/N 270875-, 280197-, 231394-
PROD NO. 8301348, S/N 270875-, 280197-, 231394-
CAB
PART NO. 11294093
PART NO. 11294094
PROD NO. 8293085
PROD NO. 8293086
PROD NO. 8293087
PROD NO. 8293088
PROD NO. 8293089
PROD NO. 8293090
PROD NO. 8293091
PROD NO. 8293092
PROD NO. 8299644
ENGINE
PROD NO 15165693
Replacement version 17231262
PROD NO 15083725
Replacement version 17231261
PROD NO 17213165
PROD NO 17213168
Part NO. VOE14880647 for Volvo EC290B(SER NO INT 13562- EU & NA 80001-)
This catalogue lists the spare parts for Excavator EC290B
BASIC MACHINE
PROD NO 8277459, EC290B, SER NO ; KOR 10001 - 16792
PROD NO 8277459, EC290B, SER NO ; CHN 30001 - 31086
PROD NO 8279533, EC290B, SER NO ; EU and NA 80001 - 81230
PROD NO 8280312, EC290B, SER NO ; INT and KOR 13562 - 16792, 30224 - 31086
ENGINE
Part No. 14500386, D7D EAE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EPA
Part No. 14519199, D7D ECE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EU
Part No. 14519200, D7D EDE2, KOR S/N 10973- / CHN S/N 30007-
Without label
Part No. 14527732, D7E EAE3, S/N 80001- Emission Certificated from EPA/EU
Part NO. VOE14880647 for Volvo ECR235D(S/N 210001-210669)
EXCAVATOR VOLVO ECR235D
BASIC MACHINE
PROD NO. 8290173, S/N 210001- 210669
CAB
PART NO. 8290225, 8291326
ENGINE
PART NO. 15176768, D6H , EU
part not stocked as spare part
PART NO. 17231343, replacement version
PART NO. 15176763, D6H, US
part not stocked as spare part
PART NO. 17231342, replacement version
Part NO. VOE14880647 for Volvo EC235D(S/N 220001-220035)
EXCAVATOR VOLVO EC235D
BASIC MACHINE
PROD NO. 8289742, S/N 220001- 220035
CAB
PART NO. 11294093, 11294094
ENGINE
PART NO. 15165690, D6H , EU
part not stocked as spare part
PART NO. 17231343, replacement version
Part NO. VOE14880647 for Volvo EC160C(120001-120962 140001-140192)
This catalogue lists the spare parts for Excavator EC160C.
BASIC MACHINE
PROD NO 8280347, EC160C, SER NO ; 120001 - 120962
PROD NO 8280347, EC160C, SER NO ; 140001 - 140192
ENGINE
Part No. 14533108, D6E EAE3, Emission Certificated from EPA and EU
