Volvo Hose assembly Part NO. VOE15114421
Part Name: VOE15114421 Hose assembly
KDSORT: 300, 210, 200, 115
UE: U
ANT1: 2, 1
GLB_ANM1: T
Hose Recipe Asmoverall Length MM: 2200
Hose Recipe Asmoverall Length Inch: 86.61
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 3
Hose Recipe Status: A
Hose Recipe Protector Length MM: 2145
Hose Recipe Protector Length INCH: 84.45
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Pilot
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: Volvo 100
Hose Part Hose Standard SAE: Volvo 100
Hose Part Hose Standard EN: Volvo 100
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Extreme lightness
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20884/916/600, 20735/916/200, 20811/916/1400, 20570/916/1400, 20675/916/1400
Looking for Part NO.VOE15114421?
We supply KATO / SAMSUNG / HYUNDAI / YANMAR / MITSUBISHI / Kubota aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE15114421 Hose assembly suitable for 1079940 Working hydraulic, dipper arm cylinder on boom. assembly.
Volvo VOE15114421(c.1079940) Pilot
Ref: 1079940 / 7 / 1
VOE11871826 / U Safety valve on boom and dipper arm
VOE11871827 / U Safety valves on boom and arm cylinders
20735/916/200
Volvo VOE15114421 Hose assembly suitable for 1068622 Working hydraulics, valves assembly.
Volvo VOE15114421(c.1068622) Hose assembly
Ref: 1068622 / 16 / 2
VOE11871564 / U Safety valve on boom and dipper arm
VOE11871354 / U Safety valve on boom and dipper arm
20675/916/1400
Volvo VOE15114421 Pilot suitable for 1094609 Working hydraulics, valves assembly.
Volvo VOE15114421(c.1094609) Hose assembly
Ref: 1094609 / 6 / 1
VOE11872137 / U Safety valve on boom and dipper arm
VOE11872138 / U / ARM & BLADE Safety valve on boom and dipper arm
20884/916/600
Volvo VOE15114421 Hose assembly suitable for 1091566 Working hydraulics, valves assembly.
Volvo VOE15114421(c.1091566) Hose assembly
Ref: 1091566 / 15 / 1
VOE11872085 / U Safety valve on boom and dipper arm
VOE11872086 / U Safety valve on boom and dipper arm
20811/916/1400
Volvo VOE15114421 Pilot suitable for 1055520 Working hydraulics, valves assembly.
Volvo VOE15114421(c.1055520) Hose assembly
Ref: 1055520 / 7 / 1
VOE11871116 / U Safety valves on boom and arm cylinders
20570/916/1400
VOLVO Construction parts supply SAMSUNG / KATO / HYUNDAI / Deutz / ISUZU / SUMITOMO aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE15114421 is on sale now!
Part NO. VOE15114421 for Volvo EC20D
EXCAVATOR VOLVO EC20D
BASIC MACHINE
PROD NO 11839926
S/N 2002-
ENGINE
Part No. 15678814
Part NO. VOE15114421 for Volvo EC20E
EXCAVATOR VOLVO EC20E
BASIC MACHINE
Product number 11839940, Serial number 20001-
CAB
Product number 11872124
Product number 11872130
ENGINE
Part number 15705402, D0.9A ST V
Part NO. VOE15114421 for Volvo ECR25D(2507-)
EXCAVATOR VOLVO ECR25D
BASIC MACHINE
PROD NO. 11839916 S/N 2507-
ENGINE
Part No. 15678903
Part NO. VOE15114421 for Volvo ECR25D(25001-)
EXCAVATOR VOLVO ECR25D
BASIC MACHINE
PROD NO. 11839941 S/N 25001-
CAB
Product number 15711295
ENGINE
Part No. 15678903 D1.1A
Part NO. VOE15114421 for Volvo EC20C
EXCAVATOR VOLVO EC20C
BASIC MACHINE
PROD NO 11839913
S/N 2038 -
ENGINE
Part No. 11808299, Type 3TNV76-WVE
