Volvo excavator spare part VOE15676614 Eternity/2
Part Name: VOE15676614 Hose assembly
KDSORT: 360, 310, 190, 140
UE: U
ANT1: 1
ANT3: 1
ANT4: 1
GLB_ANM1: S/N 4119-4128, 4145-
Hose Recipe Asmoverall Length MM: 950
Hose Recipe Asmoverall Length Inch: 37.40
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 8
Hose Part Hose Size Inch: 5/16"
Hose Part Hose Dash: -05
Hose Part Hose Pressure Class MPA: 40.0
Hose Part Hose Pressure Class PSI: 5800
Hose Part Hose Pressure Class BAR: 400
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 15
Hose Part Hose Outer Diameter INCH: 0.59
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20132/916/350, 20132/916/360, 20048/916/350, 20810/911/500
Looking for Part NO.VOE15676614?
We supply Deutz / Kobelco / ISUZU / CUMMINS / KATO / SUMITOMO aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE15676614 Eternity/2 suitable for 1091570 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE15676614(c.1091570) Hose assembly
Ref: 1091570 / 5 / 1
VOE11839930 / P / EC27D Basic Machine
20810/911/500
Volvo VOE15676614 Eternity/2 suitable for 1032736 Hydraulic circuit ( platform/balancing valve/offset cylinder ) assembly.
Volvo VOE15676614(c.1032736) Hose assembly
Ref: 1032736 / 14 / 2
20048/916/350
Volvo VOE15676614 Hose assembly suitable for 1076669 Hydraulic circuit ( platform/balancing valve/offset cylinder ) assembly.
Volvo VOE15676614(c.1076669) Hose assembly
Ref: 1076669 / 24 / 1
20132/916/360
Volvo VOE15676614 Eternity/2 suitable for 1034754 Hydraulic circuit ( platform/balancing valve/offset cylinder ) assembly.
Volvo VOE15676614(c.1034754) Hose assembly
Ref: 1034754 / 7 / 1
20132/916/350
We supply Kobelco / HYUNDAI / Komatsu / CUMMINS / Deutz / ISUZU aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.VOE15676614 is on sale now!
Part NO. VOE15676614 for Volvo EC27C
EXCAVATOR VOLVO EC27C
BASIC MACHINE
PROD NO 11839907
S/N 2742 - 5457
ENGINE
Part No. 11806934, Type 3TNV88-BSVE
Part NO. VOE15676614 for Volvo ECR38(TYPE 602)
EXCAVATOR VOLVO ECR38
BASIC MACHINE
602.10151 ECR38
ENGINE
Part No. VOE 11801176 Typ, D1.6C / D1.6A, S/N - 11342
Part No. VOE 15602421 Typ, D1,6DCAE3, S/N 11343 -
Part NO. VOE15676614 for Volvo EC27D(S/N 27001-)
EXCAVATOR VOLVO EC27D
BASIC MACHINE
PROD NO. 11839930 S/N 27001-
CAB
Product number 15711295
ENGINE
Part No. 15678903 D1.1A
