Volvo EC330B(S/N INT 10713-10806 EU&NA 80001-80425) Pilot Part NO. SA9453-02226
Part Name: SA9453-02226 Hose assembly
KDSORT: 570, 350, 400, 410, 690, 330, 580, 360, 230, 290, 420, 250, 460, 200
UE: U
ANT1: 1, 2, 3, 0002
ANT2: 0000, 1, 2
ANT3: 2, 1
ANT4: 1
ANT5: 1
GLB_ANM1: SER NO 3084-, S/N -10043, S/N 10463-, SER NO 10463-, SER NO 3472-, SER NO 3386-, S/N -18131, SER NO 4003-
GLB_ANM2: SER NO 30001-
Hose Recipe Asmoverall Length MM: 1300
Hose Recipe Asmoverall Length Inch: 51.18
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Pilot
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: Volvo 100
Hose Part Hose Standard SAE: Volvo 100
Hose Part Hose Standard EN: Volvo 100
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Extreme lightness
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20488/914/400, 20080/914/400, 20490/914/3000, 20489/914/2600, 56126/914/300, 20601/914/300, 56022/914/300, 56141/914/300, 20060/916/6010, 20052/914/100, 20489/914/2400, 56142/914/400, 56126/914/500, 20019/914/300
Looking for Part NO.SA9453-02226?
We supply KATO / Kubota / HYUNDAI / Deutz / SAMSUNG / Caterpillar aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9453-02226 Pilot suitable for 1010981 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-02226(c.1010981) Pilot
Ref: 1010981 / 18 / 1
VOE8279196 / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20021/914/2600
Volvo SA9453-02226 Pilot suitable for 1010968 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-02226(c.1010968) Hose assembly
Ref: 1010968 / 18 / 1
VOE8279196 / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20015/916/2450
Volvo SA9453-02226 Pilot suitable for 1021263 Working hydraulic, hammer and shear for upper assembly.
Volvo SA9453-02226(c.1021263) Hose assembly
Ref: 1021263 / 20 / 1
VOE8280253(VOE14545605) / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20076/916/2600
Volvo SA9453-02226 Hose assembly suitable for 1004160 Servo system, control valve to remote control valve assembly.
Volvo SA9453-02226(c.1004160) Hose assembly
Ref: 1004160 / 9 / 1
SAEF00A001 / P / MX175WS Basic Machine
56022/914/150
Volvo SA9453-02226 Hose assembly suitable for 1011018 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-02226(c.1011018) Pilot
Ref: 1011018 / 8 / 1
VOE8279193 / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20079/916/2450, 56140/916/2450
Heavy Volvo supply Komatsu / ISUZU / Kobelco / SUMITOMO / YANMAR / Deutz aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.SA9453-02226 is on sale now!
Part SA9453-02226 suitable for:
VOE8279320 / P / EW145B Basic Machine
VOE8277688(VOE14516011) / U Hydr. Quick fit equipment on basic machine
VOE8287683 / P / EW145B Basic Machine
VOE8278456(VOE14520490) / U Hydr. leak-off line for hammer-shear. 1 pump
VOE8278458(VOE14520491) / U Hydr. leak-off line for hammer-shear. 2 pump
VOE8279196 / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
Part NO. SA9453-02226 for Volvo ECR88(S/N 10001-14010)
EXCAVATOR VOLVO ECR88
This catalogue lists the spare parts for Excavator ECR88.
BASIC MACHINE
PROD NO 8278985, ECR88, Ser No 10001-14010
ENGINE
Part No. 14530219, D3.4ACAE2EC4U, Emission Certificated from EPA/EU
Part No. 14530218, D3.4ACAE2EC4K, Without label
Part NO. SA9453-02226 for Volvo EC135B(SER NO 20001-20079)
This catalogue lists the spare parts for Excavator EC135B.
BASIC MACHINE
PROD NO 8277787, EC135B, SER NO 20001-
ENGINE
Part No. 14521397, D4D EAE2, Emission Certificated from EU
Part NO. SA9453-02226 for Volvo EC700BHR(HIGH REACH DEMOLITION)
This catalogue lists the spare parts for Excavator EC700BHR.
BASIC MACHINE
PROD NO. 8285792, EC700BHR, SER NO 90001 - 90012
ENGINE
Part No. 8188186, D16E-A, Emission-certified from EPA and EU
Part NO. SA9453-02226 for Volvo EC700B(S/N 10001-10940)
This catalog lists the spare parts for Excavator EC700B.
BASIC MACHINE
PROD NO 8279230, EC700B
ENGINE
Part No. 8188183, D16EEAE3, S/N - 10337
Part No. 8188186, D16E-A, S/N 10338 -
Part NO. SA9453-02226 for Volvo EC330B(S/N INT 10713-10806 EU&NA 80001-80425)
This catalog lists the spare parts for Excavator EC330B
BASIC MACHINE
PROD NO 8277717, EC330B
PROD NO 8280270, EC330B, SER NO EU and NA 80001 - 80425
PROD NO 8279096, EC330B, SER NO INT 10713 - 10806
ENGINE
Part No. 8188768, D12D EBE3, S/N - 80425 KOR, 8280231,
Emission Certificated from EPA and EU
Part No. 8188756, D12D-H, 8280231
Part No. 8188757, D12D-P, S/N 80426 - KOR, 8280231
Part No. 8188758, D12D EBE2, S/N - 10783 KOR, 8280232,
without EPA label
Part No. 8188746, D12D-G, S/N 10784 KOR, 8280232
Part No. 8188747, D12D-O, S/N 10785 - KOR, 8280232
Part NO. SA9453-02226 for Volvo EC180B(PRIME S/N 12001-)
This catalogue lists the spare parts for Excavator EC180B.
BASIC MACHINE
PROD NO 8278983, EC180B, S/N 12001-
ENGINE
Part No. 14519207, D6D EHE2, Emission Certificated from EU
