Volvo excavator spare part SA9453-07226 Hose assembly
Part Name: SA9453-07226 Hose assembly
KDSORT: 100, 250, 240
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1300
Hose Recipe Asmoverall Length Inch: 51.18
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 4
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/2SN
Hose Part Hose Size DN: 31
Hose Part Hose Size Inch: 1.1/4"
Hose Part Hose Dash: -20
Hose Part Hose Pressure Class MPA: 14.0
Hose Part Hose Pressure Class PSI: 2030
Hose Part Hose Pressure Class BAR: 140
Hose Part Hose Standard ISO: ISO 1436
Hose Part Hose Standard SAE: SAE 100R2AT
Hose Part Hose Standard EN: EN 853 2SN
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 47
Hose Part Hose Outer Diameter INCH: 1.85
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20140/916/2300, 56121/916/1000, 20060/916/2300, 20229/916/2300, 20226/916/2300
Looking for Part NO.SA9453-07226?
We supply MITSUBISHI / HYUNDAI / Hitachi / CASE / CUMMINS / Kubota aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9453-07226 Rockmaster/2SN suitable for SD274 Working hydraulic, hammer and shear for return filter assembly.
Volvo SA9453-07226(c.SD274) Rockmaster/2SN
Ref: SD274 / 13 / 1
SADG19C001 / U Leak-off line for hammer-shear. Add return filter
56121/916/1000
Volvo SA9453-07226 Rockmaster/2SN suitable for 1029327 Working hydraulic, hammer and shear for return filter assembly.
Volvo SA9453-07226(c.1029327) Rockmaster/2SN
Ref: 1029327 / 1 / 1
VOE8285792 / P / EC700BHR Basic Machine
20226/916/2300
Volvo SA9453-07226 Rockmaster/2SN suitable for 1025542 Working hydraulic, hammer and shear for return filter assembly.
Volvo SA9453-07226(c.1025542) Hose assembly
Ref: 1025542 / 1 / 1
VOE8292808 / U Hydr. leak-off line for hammer-shear. 1 pump
VOE8284404(VOE14574344) / U Leak-off line for hammer-shear. Add return filter
20229/916/2300, 20140/916/2300
Volvo SA9453-07226 Hose assembly suitable for 1019274 Working hydraulic, hammer and shear for return filter assembly.
Volvo SA9453-07226(c.1019274) Rockmaster/2SN
Ref: 1019274 / 16 / 1
VOE8279276(VOE14541472) / U Leak-off line for hammer-shear. Add return filter
20060/916/2300
VOLVO Aftermarket offer SUMITOMO / MITSUBISHI / KATO / Kubota / Kobelco / CUMMINS aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.SA9453-07226 is on sale now!
Part NO. SA9453-07226 for Volvo EC700C(S/N 110001-110770)
This catalogue lists the spare parts for Excavator EC700C.
BASIC MACHINE
PROD NO. 8282430, EC700C, SER NO 110001 - 110770
ENGINE
Part No. 8188183, D16EEAE3, S/N - 110032, Emission-certified from EPA and EU
Part No. 8188186, D16E-A, S/N 110033 - 110770
Part NO. SA9453-07226 for Volvo EC700CHR(HIGH REACH DEMOLITION S/N 190001-190020)
EXCAVATOR VOLVO EC700C HR
BASIC MACHINE
PROD NO. 8292784, S/N 190001-190020
CAB
PROD NO. 8292789
PROD NO. 8292790
ENGINE
D16E, EU
Product No. 15187302
Replacement version 8188186
D16E, US
Product No. 15187301
Replacement version 8188186
Part NO. SA9453-07226 for Volvo EC290
This catalogue lists the spare parts for Excavator EC290
BUCKETS
Bucket GP. ESCO. 1,1/1,24 - F24
Description:
GP = General purpos, RB = Rock bucket.
ESCO = Type of bucket tooth, Esco.
1,1 = Volume CECE cubic meter.
1,24 = Volume SAE cubic meter.
S3 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR X 50
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
50 = Number of track shoes
Part NO. SA9453-07226 for Volvo EC700B(S/N 10001-10940)
This catalog lists the spare parts for Excavator EC700B.
BASIC MACHINE
PROD NO 8279230, EC700B
ENGINE
Part No. 8188183, D16EEAE3, S/N - 10337
Part No. 8188186, D16E-A, S/N 10338 -
Part NO. SA9453-07226 for Volvo EC700BHR(HIGH REACH DEMOLITION)
This catalogue lists the spare parts for Excavator EC700BHR.
BASIC MACHINE
PROD NO. 8285792, EC700BHR, SER NO 90001 - 90012
ENGINE
Part No. 8188186, D16E-A, Emission-certified from EPA and EU
