Eternity/2 VOE14250311 for Volvo excavator EC650(SER NO 539-618) excavator
Part Name: VOE14250311 Hydraulic hose
KDSORT: 190, 120, 130, 380, 430, 210, 450, 370, 220, 140, 260, 440, 250, 180
UE: U
NS_SS: OP
ANT1: 1
INFLYTT: 1
GLB_ANM1: MARKED 12, Marked 52, Marked 21, Marked 32, MARKED 41, Marked 42, Marked 52,SER NO -106, Marked 52,SER NO -270, MARKED 26, CAB ELEVATION, MARKED 25, CAB ELEVATION
Hose Recipe Asmoverall Length MM: 1800
Hose Recipe Asmoverall Length Inch: 70.87
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 36.5
Hose Part Hose Pressure Class PSI: 5293
Hose Part Hose Pressure Class BAR: 365
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 17
Hose Part Hose Outer Diameter INCH: 0.67
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 99508/916/100, 99515/914/120, 99512/916/585, 99529/914/120, 99510/914/20, 99511/911/1025, 99518/424/200, 99511/916/50, 99521/914/950, 99511/916/585, 99518/914/850, 99508/914/800, 99505/914/200, 99519/914/850
Looking for Part NO.VOE14250311?
We supply MITSUBISHI / SAMSUNG / Kobelco / SUMITOMO / Doosan / Hitachi aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE14250311 Hydraulic hose suitable for FN192 Servo pressure hydraulicsand tank back-flow lines assembly.
Volvo VOE14250311(c.FN192) Hydraulic hose
Ref: FN192 / 5 / 1
99519/914/850
Volvo VOE14250311 Eternity/2 suitable for FT331 Servo hydraulics, down shift valve assembly.
Volvo VOE14250311(c.FT331) Eternity/2
Ref: FT331 / 24 / 1
99521/914/950
Volvo VOE14250311 Hydraulic hose suitable for FP218A Servo pressure hydraulicsand tank back-flow lines assembly.
Volvo VOE14250311(c.FP218A) Eternity/2
Ref: FP218A / 5 / 1
99520/914/850
Volvo VOE14250311 Hydraulic hose suitable for FD158 Slope/grab equipment, base machine assembly.
Volvo VOE14250311(c.FD158) Hydraulic hose
Ref: FD158 / 11 / 1
VOE14258394 / U Slope-/rotation grab bucket hydraulics on
99512/916/50
Volvo VOE14250311 Hydraulic hose suitable for FD140 Joy stick, left and right assembly.
Volvo VOE14250311(c.FD140) Hydraulic hose
Ref: FD140 / 16 / 1
99512/914/20
VOLVO Parts for sale supply ISUZU / Deutz / Kobelco / Kubota / SAMSUNG / MITSUBISHI spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE14250311 is on sale now!
Part VOE14250311 suitable for:
VOE14302258 / U Hydraulic control
Part NO. VOE14250311 for Volvo EW130C ÅKERMAN(ÅKERMAN EW130C SER NO - 583)
EXCAVATOR EW130C
BASIC MACHINE
PROD NO 14301048 EW130C, SER NO 501 - 583
CAB
PROD NO 14244000
ENGINE
Part No. 14265999 TD 40 GDE
Part NO. VOE14250311 for Volvo EW230 ÅKERMAN(ÅKERMAN EW230 SER NO - 1447)
EXCAVATOR EW230
BASIC MACHINE
SER NO 1369 - 1447
ENGINE
TD 61 ACE, SER NO - 1404
TD 61 GE, SER NO 1405 -
Part NO. VOE14250311 for Volvo EC650(SER NO 539-618)
EXCAVATOR VOLVO EC650
BASIC MACHINE
PROD NO 14301037 EC650 SER NO. 539 - 618
CAB
PROD NO 14244000
ENGINE
Part No. 499288 Typ TD 122 KIE
Part NO. VOE14250311 for Volvo EC130C ÅKERMAN(ÅKERMAN EC130C SER NO - 220)
EXCAVATOR EC130C
BASIC MACHINE
PROD NO 14301047 EC130C, SER NO 201 - 220
CAB
PROD NO 14244000
ENGINE
Part No. 14265999 TD 40 GDE
Part NO. VOE14250311 for Volvo EW130C(SER NO 584-)
EXCAVATOR VOLVO EW130C
BASIC MACHINE
PROD NO 14301048 EW130C, SER NO 584 -
CAB
PROD NO 14244000
ENGINE
Part No. 14265999 TD 40 GDE
Part NO. VOE14250311 for Volvo EC390(SER NO 1001-)
EXCAVATOR VOLVO EC390
BASIC MACHINE
PROD NO 14301001 EC390, CHWL. SER NO 1001 -
CAB
PROD NO 14267000
ENGINE
Part No. 497282 Type TD 103 KAE, ENG 277745 -
