Volvo PL4608(S/N 110001 - 110086) VOE936354 Hose assembly wholesale
Part Name: VOE936354 Hose assembly
KDSORT: 280, 300, 400, 210, 200, 230, 320, 150, 170, 110, 380, 130, 350, 310
UE: U
ANT1: 1, 2
ANT2: 2
ANT3: 2
Hose Recipe Asmoverall Length MM: 650
Hose Recipe Asmoverall Length Inch: 25.59
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Xtraflex/5000
Hose Part Hose Size DN: 19
Hose Part Hose Size Inch: 3/4"
Hose Part Hose Dash: -12
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 18752-C
Hose Part Hose Standard SAE: Volvo 106
Hose Part Hose Standard EN: Volvo 106
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Extreme flexibility
Hose Part Hose Outer Diameter MM: 32
Hose Part Hose Outer Diameter INCH: 1.26
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20498/911/1600, 20633/916/2260, 20096/911/1600, 20497/911/1600, 20731/916/600, 20732/916/600, 20631/916/1000, 20141/916/1000, 20641/916/1000, 20487/911/400, 20021/911/1600, 20760/916/1000, 20633/916/1000, 20760/916/2200
Looking for Part NO.VOE936354(SA9403-05613)?
We offer MITSUBISHI / CASE / ISUZU / Caterpillar / KATO / Kobelco spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
SA9403-05613 replacement for new Part NO.VOE936354
Volvo VOE936354 Hose assembly suitable for 1078115 Working hydraulic, bucket cylinder on dipper arm assembly.
Volvo VOE936354(c.1078115) Xtraflex/5000
Ref: 1078115 / 19 / 2
VOE8291077 / U / 3,0M Leak-off line on dip. arm without leak. for grapp.
20726/916/240
Volvo VOE936354 Xtraflex/5000 suitable for 1078951 Working hydraulic, bucket cylinder on dipper arm assembly.
Volvo VOE936354(c.1078951) Hose assembly
Ref: 1078951 / 17 / 2
VOE8282264 / U / 3.0M WITHOUT GRAPPLE Grapple manoeuvre. Leak-off line on dip. arm
20740/916/330, 20730/916/240
Volvo VOE936354 Hose assembly suitable for 1097503 Working hydraulic, hammer and shear for upper assembly.
Volvo VOE936354(c.1097503) Xtraflex/5000
Ref: 1097503 / 2 / 1
VOE8297510 / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20760/916/2200, 20633/916/2260
Volvo VOE936354 Hose assembly suitable for 1097509 Working hydraulic, hammer and shear for upper assembly.
Volvo VOE936354(c.1097509) Hose assembly
Ref: 1097509 / 6 / 1
VOE8297512 / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 2 pump
VOE8297511 / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20760/916/2300, 20633/916/2225
Volvo VOE936354 Hose assembly suitable for 1078067 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE936354(c.1078067) Xtraflex/5000
Ref: 1078067 / 6 / 1
VOE8294491 / U / WITH HRV Float position for boom
20726/911/410
VOLVO Construction parts offer Kubota / Hitachi / SAMSUNG / CASE / SUMITOMO / MITSUBISHI aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE936354(SA9403-05613) is on sale now!
Part VOE936354 suitable for:
VOE8278454(VOE14521645) / U Float position for boom
VOE8278983 / P / EC180B Basic Machine
VOE8291077 / U / 3,0M Leak-off line on dip. arm without leak. for grapp.
VOE8280394 / U / 2,6M Leak-off line on dip. arm without leak. for grapp.
VOE8280395 / U / 3,0M Leak-off line on dip. arm without leak. for grapp.
VOE8280393 / U / 2,3M Leak-off line on dip. arm without leak. for grapp.
VOE8291076 / U / 2,3M Leak-off line on dip. arm without leak. for grapp.
VOE8289929 / U / 2,6M Leak-off line on dip. arm without leak. for grapp.
VOE8291077 / U / 3,0M Leak-off line on dip. arm without leak. for grapp.
VOE8284611 / U / 2.1M WITHOUT GRAPPLE Grapple manoeuvre. Leak-off line on dip. arm
VOE8282263 / U / 2.5M WITHOUT GRAPPLE Grapple manoeuvre. Leak-off line on dip. arm
VOE8282264 / U / 3.0M WITHOUT GRAPPLE Grapple manoeuvre. Leak-off line on dip. arm
VOE8280398 / U Float position for boom
Part NO. VOE936354 for Volvo ECR145E(S/N 310001-)
EXCAVATOR VOLVO ECR145E
BASIC MACHINE
Product number 8296283, Serial number 310001-
CAB
Product number 8295958
Product number 8297796
Product number 8297797
Product number 8297798
Product number 8301655
Product number 8301656
Product number 8301657
Product number 8301658
ENGINE
Product number 17229198, D4 T4f
Product number 17229196, D4 T4f
Product number 17480990, D4 T4f
Product number 17506991, D4J T4f
Product number 17668804, D4 STAGE V
Part NO. VOE936354 for Volvo PL4608(S/N 110001 - 110086)
This catalogue lists the spare parts for Pipe Layer PL4608.
BASIC MACHINE
PROD NO. 8287463, PL4608, SER NO. 110001 - 110086
ENGINE
Part No. 8188764, D12D EAE3, S/N - 110268, 8279675
Emission-certified from EPA and EU
Part No. 8188756, D12D-H, S/N 110269 - 110363, 8279675
Part No. 8188757, D12D-P, S/N 110364 - , 8279675
Part NO. VOE936354 for Volvo EC460C(S/N 115001-115434)
This catalogue lists spare parts for Excavator EC460C.
BASIC MACHINE
PROD NO. 8280026, EC460C, S/N 115001 - 115434
ENGINE
Part No. 8188757, D12D-P, 8286626,
Emission-certified from EPA and EU
Part NO. VOE936354 for Volvo EC140E(S/N 310001-)
EXCAVATOR VOLVO EC140E
BASIC MACHINE
Product number 8295469, Serial number 310001-
CAB
Product number 8297212
Product number 8297213
Product number 8297211
Product number 8295481
Product number 8297214
Product number 8300791
Product number 8301651
Product number 8301652
Product number 8301653
Product number 8301654
ENGINE
Replacement version 17506989
Replacement version 17668802
Replacement version 17229187
Replacement version 17229186
Part NO. VOE936354 for Volvo EC120D(S/N 230001-)
EXCAVATOR VOLVO EC120D
BASIC MACHINE
PROD NO. 8290120, S/N 230001-
SUB BASIC MACHINE
Product number 8297469, Serial number 230001-
CAB
Product number 8299032
ENGINE
PART NO. 17429616, T3
Part NO. VOE936354 for Volvo EC140C(S/N 110001-111312)
This catalogue lists the spare parts for Excavator EC140C.
BASIC MACHINE
PROD NO. 8282939, EC140C, SER NO ; 110001 - 111312
ENGINE
Part No. 14536072, D4E EBE3 : Emission-certified from EPA and EU
