Pilot VOE937202 for Volvo excavator EC180D(S/N 220001-220161) excavator
Part Name: VOE937202 Hose assembly
KDSORT: 210, 220, 190, 150, 110, 170, 230, 100, 180
UE: U
ANT1: 4, 1
ANT2: 1
ANT3: 1
Hose Recipe Asmoverall Length MM: 2050
Hose Recipe Asmoverall Length Inch: 80.71
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 3
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Pilot
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: Volvo 100
Hose Part Hose Standard SAE: Volvo 100
Hose Part Hose Standard EN: Volvo 100
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Extreme lightness
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20096/914/2100, 20633/914/300, 20631/914/2100, 20632/914/2100, 20141/914/300, 20141/914/2600, 20632/914/2150, 20141/914/2500, 20730/914/400, 20631/914/2150, 20095/914/2100, 20141/914/2550
Looking for Part NO.VOE937202?
We supply Doosan / Deutz / ISUZU / KATO / Kobelco / SAMSUNG aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE937202 Hose assembly suitable for 1029317 Servo system, hammer and shear assembly.
Volvo VOE937202(c.1029317) Pilot
Ref: 1029317 / 12 / 3
VOE8284617(VOE14611811) / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 2 pump
VOE8284614(VOE14611810) / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
VOE8283007(VOE14579612) / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 2 pump
20141/914/2550
Volvo VOE937202 Hose assembly suitable for 1079573 Servo system, control valve to solenoid valve assembly.
Volvo VOE937202(c.1079573) Pilot
Ref: 1079573 / 12 / 1
VOE8295469 / P / EC140E Basic Machine
20730/914/400
Volvo VOE937202 Hose assembly suitable for 1028288 Servo system, hammer and shear assembly.
Volvo VOE937202(c.1028288) Pilot
Ref: 1028288 / 2 / 1
VOE8283006(VOE14579611) / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20141/914/2600
Volvo VOE937202 Hose assembly suitable for 1028275 Servo system, control valve to solenoid valve assembly.
Volvo VOE937202(c.1028275) Hose assembly
Ref: 1028275 / 12 / 1
VOE8282939 / P / EC140C Basic Machine
20141/914/300
Volvo VOE937202 Pilot suitable for 1028286 Servo system, hammer and shear assembly.
Volvo VOE937202(c.1028286) Hose assembly
Ref: 1028286 / 8 / 1
VOE8283005 / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20141/914/2500
VOLVO Aftermarket offer Hitachi / Deutz / Kobelco / YANMAR / CASE / ISUZU aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.VOE937202 is on sale now!
Part VOE937202 suitable for:
VOE8290120 / U / EC140D Basic Machine
VOE8290140 / U / IF NOT EQUIPMENT Leak-off line for slope-rotator on basic machine
VOE8298965 / P / SUB BASIC MACHINE FOR D Basic Machine
VOE8287099 / U / PLUS PART (PLUGS) - NO QUICK FIT Pilot block piping
VOE8279849 / U / IF NOT EQUIPPED Servo control pattern change for lever control
VOE8289931 / U / IF NOT EQUIPPED Servo control pattern change for lever control
VOE8289930 / U Servo control pattern change for lever control
VOE8280397 / U / WITHOUT Servo control pattern change for lever control
VOE8280396 / U Servo control pattern change for lever control
Part NO. VOE937202 for Volvo EC160C(120001-120962 140001-140192)
This catalogue lists the spare parts for Excavator EC160C.
BASIC MACHINE
PROD NO 8280347, EC160C, SER NO ; 120001 - 120962
PROD NO 8280347, EC160C, SER NO ; 140001 - 140192
ENGINE
Part No. 14533108, D6E EAE3, Emission Certificated from EPA and EU
Part NO. VOE937202 for Volvo EC140D(210001-211217, 240001- 230001-,270001-, 280001-)
EXCAVATOR VOLVO EC140D
BASIC MACHINE
PROD NO. 8290120, S/N 210001-211217, 230001-, 270001-, 280001-, 240001-
SUB BASIC MACHINE
Product number 8297469, Serial number 230001-, 270001-, 280001-, 240001-
Product number 8298965, Serial number 230001-, 270001-, 280001-, 240001-
Product number 8301355, Serial number 270115-, 280087-, 230098-
Product number 8301356, Serial number 270115-, 280087-, 230098-
CAB
Product number 8292094
Product number 8292095
Product number 8292096
Product number 8292097
Product number 8298971
Product number 8298972
Product number 8298973
Product number 8298974
Product number 8299032
ENGINE
PART NO. 15165682, D4H , EU
part not stocked as spare part
PART NO. 17231718, replacement version
PART NO. 15083700, D4H, US
part not stocked as spare part
PART NO. 17231717, replacement version
PART NO. 17429616, T3
PART NO. 17417558, T2
Part NO. VOE937202 for Volvo EC180D(S/N 220001-220161)
EXCAVATOR VOLVO EC180D
BASIC MACHINE
PROD NO. 8289851, S/N 220001-220161
CAB
PART NO. 11294093, 11294094
ENGINE
PART NO. 15165685, D4H , EU
part not stocked as spare part
PART NO. 17231615, replacement version
PART NO. 15083709, D4H, US
part not stocked as spare part
PART NO. 17231613, replacement version
Part NO. VOE937202 for Volvo EC140E(S/N 310001-)
EXCAVATOR VOLVO EC140E
BASIC MACHINE
Product number 8295469, Serial number 310001-
CAB
Product number 8297212
Product number 8297213
Product number 8297211
Product number 8295481
Product number 8297214
Product number 8300791
Product number 8301651
Product number 8301652
Product number 8301653
Product number 8301654
ENGINE
Replacement version 17506989
Replacement version 17668802
Replacement version 17229187
Replacement version 17229186
Part NO. VOE937202 for Volvo EC140C(S/N 110001-111312)
This catalogue lists the spare parts for Excavator EC140C.
BASIC MACHINE
PROD NO. 8282939, EC140C, SER NO ; 110001 - 111312
ENGINE
Part No. 14536072, D4E EBE3 : Emission-certified from EPA and EU
Part NO. VOE937202 for Volvo EC180C(120001-120305)
This catalogue lists the spare parts for Excavator EC180C.
BASIC MACHINE
PROD NO 8280347, EC180C, SER NO ; 120001 - 120305
ENGINE
Part No. 14533108, D6E EAE3, Emission Certificated from EPA and EU
