Hose assembly RM13365127 for Volvo excavator SD160/SD190/SD200(S/N 197386 -) excavator
Part Name: RM13365127 Hose assembly
KDSORT: 180, 220, 120, 170
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 635
Hose Recipe Asmoverall Length Inch: 25.00
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 21
Hose Part Hose Outer Diameter INCH: 0.83
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20173/911/200, 20212/911/300, 20212/911/350, 20173/911/254, 20173/911/252
Looking for Part NO.RM13365127?
We supply Komatsu / MITSUBISHI / SUMITOMO / KATO / CUMMINS / Deutz aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo RM13365127 Hose assembly suitable for 1052241 Hoses Installation assembly.
Volvo RM13365127(c.1052241) Hose assembly
Ref: 1052241 / 15 / 1
20212/911/300
Volvo RM13365127 Hose assembly suitable for 1037921 Rear Frame Hoses Installation assembly.
Volvo RM13365127(c.1037921) Hose assembly
Ref: 1037921 / 14 / 1
20173/911/200
Volvo RM13365127 Hose assembly suitable for 1052242 Hoses Installation assembly.
Volvo RM13365127(c.1052242) Eternity/2
Ref: 1052242 / 15 / 1
20212/911/350
Volvo RM13365127 Hose assembly suitable for 1051405 Rear Frame Hoses Installation assembly.
Volvo RM13365127(c.1051405) Eternity/2
Ref: 1051405 / 14 / 1
VOE13190525 / U / SD25D Basic Machine
VOE13190640 / U / SD25F Basic Machine
20173/911/252
Volvo RM13365127 Eternity/2 suitable for 1051407 Rear Frame Hoses Installation assembly.
Volvo RM13365127(c.1051407) Hose assembly
Ref: 1051407 / 14 / 1
VOE13190525 / U / SD25D Basic Machine
VOE13190640 / U / SD25F Basic Machine
20173/911/254
VOLVO Aftermarket offer MITSUBISHI / Kobelco / Hitachi / Komatsu / CUMMINS / HYUNDAI spare parts. MOQ 1 pcs is available! Volvo Part NO.RM13365127 is on sale now!
Part NO. RM13365127 for Volvo SD25/D/F(S/N 197379-, 197384- 227001-)
Soil compactors; Volvo SD25/SD25D/SD25F
PRODUCT VERSION
SD25D Vibratory compactor, S/N 197379 - 226685
SD25F Vibratory compactor, S/N 197384 - 226733
SD25 Vibratory compactor, S/N 227001 -
ENGINE
RM 13412119 Engine, S/N -201053
RM 43853829 Engine, S/N 201053 -
In June, 2008, a new ISO 17-digit standard for Product Identification Number PIN was
implemented in Shippensburg.
The illustration below shows the significance of each set of digits that make up the PIN,
including the familiar Machine Serial Number. The serial number will continue to be used
in the main business systems as a key reference.
1. World Manufacturer Identifier characters 1-3 VCE
>VCE00D38L00199553VCE00D38L00199553VCE00D38L00199553VCE00D38L00199553
Part NO. RM13365127 for Volvo SD160/SD190/SD200(S/N 197386 -)
Soil compactors; Volvo SD160/DX/F, SD190/DX, SD200/DX/F
PRODUCT VERSION
SD160DX Vibratory compactor, S/N 197540 - 226726, USA
SD160F Vibratory compactor, S/N 197540 - 225917, USA
SD160 Vibratory compactor, EU
SD190DX Vibratory compactor, S/N 197455 - 226681, USA
SD190 Vibratory compactor, EU
SD200DX Vibratory compactor, S/N 197386 -, USA
SD200DX Vibratory compactor, S/N 53806 -, CHINA
SD200F, Vibratory compactor, S/N 197386 -, USA
SD200 Vibratory compactor, EU
ENGINE
RM 43801414 Engine SD160, S/N - 225839
RM 46673984 Engine SD160, S/N 225840 -
RM 43920610 Engine SD190/SD200
In June, 2008, a new ISO 17-digit standard for Product Identification Number PIN was
implemented in Shippensburg.
The illustration below shows the significance of each set of digits that make up the PIN,
including the familiar Machine Serial Number. The serial number will continue to be used
in the main business systems as a key reference.
1. World Manufacturer Identifier characters 1-3 VCE
>VCE00D38L00199553VCE00D38L00199553VCE00D38L00199553VCE00D38L00199553
