Volvo excavator part SA9453-02351 Rockmaster/1SC for sale
Volvo excavator part SA9453-02351 Rockmaster/1SC for sale

Volvo excavator part SA9453-02351 Rockmaster/1SC for sale

VOLVO-SA9453-02351-in-stock

View

View

Volvo excavator part SA9453-02351 Rockmaster/1SC for sale

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo excavator spare part SA9453-02351 Rockmaster/1SC

Part Name: SA9453-02351 Hose assembly
KDSORT: 480, 620
UE: U
ANT1: 1
ANT2: 1
GLB_ANM1: SER NO 3001-3167
Hose Recipe Asmoverall Length MM: 1050
Hose Recipe Asmoverall Length Inch: 41.34
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 26.0
Hose Part Hose Pressure Class PSI: 3770
Hose Part Hose Pressure Class BAR: 260
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 56123/916/1200, 56123/914/400
Looking for Part NO.SA9453-02351?
We offer Hitachi / ISUZU / YANMAR / SUMITOMO / SAMSUNG / Deutz spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
SA9453-02351 for Volvo Working hydraulic, hammer and shear for 1st pump flow(SF274 assembly)
Volvo SA9453-02351 Rockmaster/1SC suitable for SF274 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-02351(c.SF274) Rockmaster/1SC
Ref: SF274 / 44 / 2
SADJ19A001 / U Hydr. leak-off line for hammer-shear. 1 pump
SADJ19B001 / U Hydr. leak-off line for hammer-shear. 2 pump
56123/916/1200
SA9453-02351 for Volvo Servo system, pump to control valve(SF257A assembly)
Volvo SA9453-02351 Hose assembly suitable for SF257A Servo system, pump to control valve assembly.
Volvo SA9453-02351(c.SF257A) Hose assembly
Ref: SF257A / 35 / 1
SADJ00A001 / P / EC460 Basic Machine
56123/914/400
We offer ISUZU / Kubota / Komatsu / KATO / Doosan / HYUNDAI spare parts. MOQ 1 pcs is available! Volvo Part NO.SA9453-02351 is on sale now!
Part NO. SA9453-02351 for Volvo EC460
EXCAVATOR VOLVO EC460
BASIC MACHINE
PROD NO DJ00A001 EC460
ENGINE
Part No. 1111-00791 Typ, MTA11-C
Part No. 1111-00841 Typ, LTA10-C for tropics
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original SA9453-02351 included regular invoice.
Used/Second hand SA9453-02351 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
