Volvo EC210B(PRIME S/N 35-,40-,50-, 70-,80-,81-,90-,95-95057) SA9459-05620 Shieldmaster/5000 wholesale
Part Name: SA9459-05620 Hose
KDSORT: 230, 130, 260, 250, 120, 290, 100, 220, 150, 240, 110, 310
UE: U
ANT1: 1, 2
ANT2: 2, 1
ANT3: 2, 1
GLB_ANM1: SER NO 3215-
Hose Recipe Asmoverall Length MM: 1350
Hose Recipe Asmoverall Length Inch: 53.15
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Shieldmaster/5000
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 34.5
Hose Part Hose Pressure Class PSI: 5003
Hose Part Hose Pressure Class BAR: 345
Hose Part Hose Standard ISO: Volvo 104
Hose Part Hose Standard SAE: Volvo 104
Hose Part Hose Standard EN: Volvo 104
Hose Part Hose Standard MSHA: _
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: Outstanding abrasion resistance
Hose Part Hose Outer Diameter MM: 18
Hose Part Hose Outer Diameter INCH: 0.71
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20431/924/750, 20226/924/700, 20629/924/1800, 20431/924/700, 56121/924/500, 20060/924/750, 20078/924/1600, 56122/924/500, 20078/924/700, 56139/924/700, 56122/924/600, 56117/924/500, 56117/924/600, 20460/924/1610
Looking for Part NO.SA9459-05620?
We supply Komatsu / Deutz / ISUZU / Kubota / Doosan / HYUNDAI spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9459-05620 Hose suitable for 1029627 Working hydraulic, quick fit on dipper arm assembly.
Volvo SA9459-05620(c.1029627) Hose
Ref: 1029627 / 9 / 3
VOE8282888 / U / 4,2M Hydr. Quick fit equipment on dipper arm
VOE8282887 / U / 3,55M Hydr. Quick fit equipment on dipper arm
VOE8282886 / U / 2,9M Hydr. Quick fit equipment on dipper arm
20226/924/700
Volvo SA9459-05620 Hose suitable for 1029594 Working hydraulic, slope and rotator on dipper arm assembly.
Volvo SA9459-05620(c.1029594) Shieldmaster/5000
Ref: 1029594 / 4 / 2
VOE8284216 / U Leak-off line for slope-rotator on boom
VOE8283578 / U Leak-off line for slope-rotator on boom
VOE8289502 / U / 2,9M Leak-off line for slope-rotator on dipper arm
VOE8283505 / U Leak-off line for slope-rotator on boom
20136/924/1610, 20135/924/1610, 20629/924/1800, 20460/924/1610, 20144/924/1610
Volvo SA9459-05620 Hose suitable for 1049425 Working hydraulic, slope and rotator on dipper arm assembly.
Volvo SA9459-05620(c.1049425) Shieldmaster/5000
Ref: 1049425 / / 2
VOE8277544(VOE14515998) / U / 3,05m Leak-off line for slope-rotator on dipper arm
VOE8289343 / U / 2,75M Leak-off line for slope-rotator on dipper arm
VOE8277543(VOE14515992) / U / 2,55m Leak-off line for slope-rotator on dipper arm
VOE8287370 / U / 3,7M Leak-off line for slope-rotator on dipper arm
20431/924/1600
Volvo SA9459-05620 Hose suitable for SD282A Rotator hydraulic, dipper arm assembly.
Volvo SA9459-05620(c.SD282A) Hose
Ref: SD282A / / 4
SADG18D002 / U / 3,05m Leak-off line for slope-rotator on Hd dipper arm
SADG18D001 / U / 2,55m Leak-off line for slope-rotator on dipper arm
SADG18D003 / U / 4,0m Leak-off line for slope-rotator on dipper arm
56121/924/500
Volvo SA9459-05620 Shieldmaster/5000 suitable for SA290 Quickfit hydraulic, dipper arm assembly.
Volvo SA9459-05620(c.SA290) Shieldmaster/5000
Ref: SA290 / 2 / 1
SADD50A001 / U / S1 Quick fit
SADD20D003 / U / 3,9m Hydr. Quick fit equipment on dipper arm
SADD20D002 / U / 2,9m Leak-off line for Quick fit equipm. on Hd dip arm
SADD20D001 / U / 2,3m Hydr. Quick fit equipment on dipper arm
56117/924/600
VOLVO Parts for sale supply MITSUBISHI / Kobelco / KATO / Deutz / SAMSUNG / YANMAR aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.SA9459-05620 is on sale now!
Part SA9459-05620 suitable for:
VOE8287377(VOE14603590) / U / 3,7M UQF Hydr. Quick fit equipment on dipper arm
VOE8284909 / U / 5,2M Hydr. Quick fit equipment on dipper arm
SADH20D002 / U / 3,1m Hydr. Quick fit equipment on dipper arm
SADH50A001 / U / S3 Quick fit
SADH20D001 / U / 2,6m Hydr. Quick fit equipment on dipper arm
SADH20D003 / U / 3,9m Hydr. Quick fit equipment on dipper arm
SADG20D002 / U / 3,05m Leak-off line for Quick fit equipm. on Hd dip arm
SADG20D001 / U / 2,55m Hydr. Quick fit equipment on dipper arm
SADG20D003 / U / 4,0m Hydr. Quick fit equipment on dipper arm
SADG50A001 / U / S3 Quick fit
SADH18D002 / U / 3,1m Leak-off line for slope-rotator on dipper arm
SADH18D003 / U / 3,9m Leak-off line for slope-rotator on dipper arm
SADH18D001 / U / 2,6m Leak-off line for slope-rotator on dipper arm
Part NO. SA9459-05620 for Volvo EC290
This catalogue lists the spare parts for Excavator EC290
BUCKETS
Bucket GP. ESCO. 1,1/1,24 - F24
Description:
GP = General purpos, RB = Rock bucket.
ESCO = Type of bucket tooth, Esco.
1,1 = Volume CECE cubic meter.
1,24 = Volume SAE cubic meter.
S3 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR X 50
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
50 = Number of track shoes
Part NO. SA9459-05620 for Volvo EC210
This catalogue lists the spare parts for Excavator EC210
BUCKETS
Bucket GP. ESCO. 0,86/0,95 - F24
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
0,86 = Volume CECE cubic meter.
0,95 = Volume SAE cubic meter.
S1 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR X 49
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
49 = Number of track shoes
Part NO. SA9459-05620 for Volvo EC290B
This catalogue lists the spare parts for Excavator EC290B
BASIC MACHINE
PROD NO 8277459, EC290B, KOR S/N 10001 - 13561
PROD NO 8277459, EC290B, CHN S/N 30001 -
ENGINE
Part No. 14500386, D7D EAE2, S/N 10001-10972
Part No. 14500386, D7D EAE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EPA
Part No. 14519199, D7D ECE2, KOR S/N 10973- / CHN S/N 30007-
Emission Certificated from EU
Part No. 14519200, D7D EDE2, KOR S/N 10973- / CHN S/N 30007-
Without label
Part NO. SA9459-05620 for Volvo EC700BHR(HIGH REACH DEMOLITION)
This catalogue lists the spare parts for Excavator EC700BHR.
BASIC MACHINE
PROD NO. 8285792, EC700BHR, SER NO 90001 - 90012
ENGINE
Part No. 8188186, D16E-A, Emission-certified from EPA and EU
Part NO. SA9459-05620 for Volvo EC210B(PRIME S/N 35-,40-,50-, 70-,80-,81-,90-,95-95057)
This catalogue lists the spare parts for Excavator EC210B.
BASIC MACHINE
PROD NO 8277784, EC210B, CHN S/N 35001 - 39999
PROD NO 8277784, EC210B, CHN S/N 90001 - 92051
PROD NO 8277784, EC210B, CHN S/N 95001 - 95057
PROD NO 8277784, EC210B, BRA S/N 40001 - 41093
PROD NO 8277784, EC210B, IND S/N 50001 - 52370
PROD NO 8277784, EC210B, KOR S/N 70001 - 79999
PROD NO 8277784, EC210B, KOR S/N 80001 - 80188
PROD NO 8277784, EC210B, KOR S/N 81001 -
ENGINE
Part No. 14536076, D6E EAE3, Emission Certificated from EPA and EU
Part No. 14536073, D6E EAE2, Without label
Part NO. SA9459-05620 for Volvo EC700B(S/N 10001-10940)
This catalog lists the spare parts for Excavator EC700B.
BASIC MACHINE
PROD NO 8279230, EC700B
ENGINE
Part No. 8188183, D16EEAE3, S/N - 10337
Part No. 8188186, D16E-A, S/N 10338 -
