Rockmaster/4SP VOE14341319 for Volvo excavator EC340(SER NO 1001-) excavator
Part Name: VOE14341319 Hydraulic hose
KDSORT: 140, 160
UE: U
NS_SS: OP
ANT1: 1
ANT2: 1
Hose Recipe Asmoverall Length MM: 1900
Hose Recipe Asmoverall Length Inch: 74.80
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/4SP
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 42.0
Hose Part Hose Pressure Class PSI: 6090
Hose Part Hose Pressure Class BAR: 420
Hose Part Hose Standard ISO: ISO 3862 4SP
Hose Part Hose Standard SAE: Volvo 102
Hose Part Hose Standard EN: EN 856 4SP
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 25
Hose Part Hose Outer Diameter INCH: 0.98
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 99522/916/1900, 99521/916/1900
Looking for Part NO.VOE14341319?
We supply HYUNDAI / Kubota / SUMITOMO / Kobelco / SAMSUNG / CASE aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE14341319 Hydraulic hose suitable for FT354 Slope bucket and grab equipment on 6.0m, 6,7mm assembly.
Volvo VOE14341319(c.FT354) Hydraulic hose
Ref: FT354 / 3,4 / 3
99521/916/1900
Volvo VOE14341319 Hydraulic hose suitable for FU354 Slope bucket and grab equipment on 6.0m, 7.0m assembly.
Volvo VOE14341319(c.FU354) Rockmaster/4SP
Ref: FU354 / 3,4 / 2
99522/916/1900
VOLVO Construction parts supply YANMAR / Komatsu / Hitachi / Kobelco / HYUNDAI / ISUZU spare parts. MOQ 1 pcs is available! Volvo Part NO.VOE14341319 is on sale now!
Part NO. VOE14341319 for Volvo EC390(SER NO 1001-)
EXCAVATOR VOLVO EC390
BASIC MACHINE
PROD NO 14301001 EC390, CHWL. SER NO 1001 -
CAB
PROD NO 14267000
ENGINE
Part No. 497282 Type TD 103 KAE, ENG 277745 -
Part NO. VOE14341319 for Volvo EC340(SER NO 1001-)
EXCAVATOR VOLVO EC340
BASIC MACHINE
PROD NO 14301000 EC340, CLNL. SER NO 1001 -
PROD NO 14301002 EC340, CLWL. SER NO 1001 -
CAB
PROD NO 14267000
ENGINE
Part No. 497282 Type TD 103 KAE, ENG 277745 -
