Eternity/2 VOE15187368 for Volvo excavator EC140E(S/N 310001-) excavator
Part Name: VOE15187368 Hose assembly
KDSORT: 130, 150, 140, 370, 200
UE: U
ANT1: 1
Hose Recipe Asmoverall Length MM: 1400
Hose Recipe Asmoverall Length Inch: 55.12
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 21
Hose Part Hose Outer Diameter INCH: 0.83
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20730/924/2410, 20752/645/600, 20751/645/600, 20753/645/600, 20730/924/2400, 20743/645/100
Looking for Part NO.VOE15187368?
We offer ISUZU / CASE / MITSUBISHI / Hitachi / Caterpillar / SAMSUNG spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE15187368 Hose assembly suitable for 1081397 Hydraulic system, steering line assembly.
Volvo VOE15187368(c.1081397) Eternity/2
Ref: 1081397 / 14 / 1
VOE8296178 / P / EW140E Excavator
20743/645/100
Volvo VOE15187368 Hose assembly suitable for 1083757 Steering system assembly.
Volvo VOE15187368(c.1083757) Eternity/2
Ref: 1083757 / 3,4 / 2
VOE54507 / P / L60GZ Wheel Loader
20751/645/600
Volvo VOE15187368 Eternity/2 suitable for 1083756 Steering system assembly.
Volvo VOE15187368(c.1083756) Hose assembly
Ref: 1083756 / 3 / 1
VOE54508 / P / L90GZ Wheel Loader
20752/645/600
Volvo VOE15187368 Hose assembly suitable for 1083754 Steering system assembly.
Volvo VOE15187368(c.1083754) Eternity/2
Ref: 1083754 / 7 / 1
VOE54509 / P / L120GZ Wheel Loader
20753/645/600
Volvo VOE15187368 Hose assembly suitable for 1079426 Working hydraulic, slope and rotator on upper frame assembly.
Volvo VOE15187368(c.1079426) Hose assembly
Ref: 1079426 / 3 / 1
VOE8297225 / U / PROPORTIONAL CONTROL Leak-off line for slope-rotator on basic machine
VOE8297224 / U / ON/OFF_40LPM Leak-off line for slope-rotator on basic machine
VOE8295489 / U / PROPORTIONAL CONTROL, 60LPM Leak-off line for slope-rotator on basic machine
VOE8297226 / U / ON/OFF_60LPM Leak-off line for slope-rotator on basic machine
20730/924/2400, 20730/924/2410
We supply YANMAR / KATO / SAMSUNG / HYUNDAI / Caterpillar / ISUZU aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.VOE15187368 is on sale now!
Part NO. VOE15187368 for Volvo L90GZ
WHEEL LOADER VOLVO L90GZ
BASIC MACHINE
PROD NO 54508, S/N 679503-
CAB
PROD NO 54514
TRANSMISSION
PROD NO 22717, HTE110C
DRIVING AXLE
PROD NO 56008, AWB 25, front
PROD NO 56011, AWB 20, rear
PROD NO 56010, AWB 20, rear, Limited slip Diff LSD
LOADING UNIT
PROD NO 33034
ENGINE
PART NO 17258797 D6 TIER3
Part NO. VOE15187368 for Volvo EW140E(S/N 310001-)
EXCAVATOR VOLVO EW140E
BASIC MACHINE
Product number 8296178, Serial number 310001-
CAB
Product number 8296190
Product number 8299054
DRIVE AXLES
Part number 14646881, front
Part number 14646882, rear
TRANSMISSION
Part number 14643849
ENGINE
Product number 17211911, D4J T4F
Product number 17211912, D4J T4F
Product number 17668806, D4 STAGE V
Part NO. VOE15187368 for Volvo EC140E(S/N 310001-)
EXCAVATOR VOLVO EC140E
BASIC MACHINE
Product number 8295469, Serial number 310001-
CAB
Product number 8297212
Product number 8297213
Product number 8297211
Product number 8295481
Product number 8297214
Product number 8300791
Product number 8301651
Product number 8301652
Product number 8301653
Product number 8301654
ENGINE
Replacement version 17506989
Replacement version 17668802
Replacement version 17229187
Replacement version 17229186
Part NO. VOE15187368 for Volvo L120GZ
WHEEL LOADER VOLVO L120GZ
BASIC MACHINE
PROD NO 54509, S/N 671503-
CAB
PROD NO. 54510
TRANSMISSION
PROD NO. 22593, HTE205B
PROD NO. 22722, HTE205C
DRIVE AXLES
PROD NO. 56005, AWB 31, front
PROD NO. 56006, AWB 30, rear
PROD NO. 56007, AWB 30, rear. 83041
LOADER UNIT
PROD NO. 33029, LU L120G LUB
PROD NO. 33039, LU 120G LB LUB, 84901
ENGINE
Part number 17258799 D7 TIER3
Part NO. VOE15187368 for Volvo L60GZ
WHEEL LOADER VOLVO L60GZ
BASIC MACHINE
PROD NO 54507, S/N 676503-
CAB
PROD NO 54511
TRANSMISSION
PROD NO 22717, HTE110C
DRIVING AXLE
PROD NO 56014, AWB 15, front
PROD NO 56056, AWB 15, rear
PROD NO 56055, rear, Limited slip Diff LSD
LOADING UNIT
PROD NO 33031
ENGINE
PART NO 17258796 D6 TIER3
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original VOE15187368 included regular invoice.
Used/Second hand VOE15187368 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
