Volvo EC55C(S/N 110001- S/N 120001-125789) excavator spare part VOE936495 Eternity/2
Part Name: VOE936495 Hose assembly
KDSORT: 350, 110, 370
UE: U
ANT1: 1
ANT2: 1
ANT3: 1
Hose Recipe Asmoverall Length MM: 250
Hose Recipe Asmoverall Length Inch: 9.84
Hose Recipe Asmoverall Length ToL MM: +/- 3mm
Hose Recipe Asmoverall Length ToL inch: +/- 0.118"
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 3 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 36.5
Hose Part Hose Pressure Class PSI: 5293
Hose Part Hose Pressure Class BAR: 365
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 17
Hose Part Hose Outer Diameter INCH: 0.67
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20455/911/400, 20155/911/400, 20455/911/410, 20155/911/410, 20747/911/500, 20747/911/400
Looking for Part NO.VOE936495?
We supply Komatsu / Deutz / Kubota / SAMSUNG / YANMAR / Doosan spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE936495 Eternity/2 suitable for 1029186 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE936495(c.1029186) Eternity/2
Ref: 1029186 / 25 / 1
VOE8289359 / U / OFFSET Upper frame
VOE8282607 / U / OFFSET Upper frame
20155/911/400, 20455/911/400
Volvo VOE936495 Hose assembly suitable for 1029187 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE936495(c.1029187) Hose assembly
Ref: 1029187 / 25 / 1
VOE8282608 / U / FIXED Upper frame
VOE8289360 / U / FIX Upper frame
VOE8290472 / U Boom leak with Hose rupture
VOE8290473 / U Boom leak with Hose rupture
VOE8289030 / U Upper frame
20455/911/410, 20155/911/410
Volvo VOE936495 Hose assembly suitable for 1081216 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE936495(c.1081216) Eternity/2
Ref: 1081216 / 2 / 1
VOE8296646 / U / EC60E BOOM SWING TYPE Sub Basic Machine
20747/911/500
Volvo VOE936495 Eternity/2 suitable for 1081150 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE936495(c.1081150) Hose assembly
Ref: 1081150 / 2 / 1
VOE8296645 / U / EC60E BOOM FIXED TYPE Sub Basic Machine
20747/911/400
VOLVO Parts for sale supply Caterpillar / KATO / Komatsu / MITSUBISHI / YANMAR / ISUZU aftermarket parts. MOQ 1 pcs is available! Volvo Part NO.VOE936495 is on sale now!
Part NO. VOE936495 for Volvo EC60E(S/N 310001-)
EXCAVATOR VOLVO EC60E
BASIC MACHINE
Product number 8296644, Serial number 310001-
CAB
Product number 8296658
ENGINE
Replacement version 17317581
Replacement version 17413984
Replacement version 17413985
Replacement version 17417548
Part NO. VOE936495 for Volvo EC55C(S/N 110001- S/N 120001-125789)
This catalogue lists the spare parts for Excavator EC55C.
BASIC MACHINE
PROD NO 8282566, EC55C, SER NO 110001 - / 120001-125789
ENGINE
Part No. 14546121, D3.1DCBE3
Part No. 14546122, D3.1DCAE2
Part No. 14591757, D3.4DCDE3, S/N -121069
Part No. 14617295, D3.4DCDE3, S/N 121070-
Part NO. VOE936495 for Volvo EC60C(S/N 110001-111939 S/N 130001-130015,131001-)
EXCAVATOR VOLVO EC60C
BASIC MACHINE
PROD NO 8282566, EC60C, SER NO 110001-111939, 130001-130015, 131001-
SUB BASIC MACHINE
Product number 8294563, Serial number 111590-111939
Product number 8299198, Serial number 131001-
CAB
Product number 8284722
Product number 8288949
Product number 8292133
Product number 8299200
ENGINE
Part No. 14546121, 4TNV94L-XVC6U, Emission-Certified from EPA/EU
Part No. 14592720, 4TNV94L-XVC6K, Without label
Part No. 14650072
Part No. 14699895, T3
