Pilot SA9453-02236 for Volvo excavator excavator
Part Name: SA9453-02236 Hose assembly
KDSORT: 400, 290, 380, 190, 570, 450, 320, 230, 520, 590, 210, 310, 350, 460
UE: U
ANT1: 1, 2, 8
ANT2: 0000
ANT3: 2, 1
GLB_ANM1: SER NO 3286-, SER NO 3472-, SER NO 70264-, SER NO 3386-, SER NO 10001-10093
GLB_ANM2: SER NO 80036-
Hose Recipe Asmoverall Length MM: 1800
Hose Recipe Asmoverall Length Inch: 70.87
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Pilot
Hose Part Hose Size DN: 6
Hose Part Hose Size Inch: 1/4"
Hose Part Hose Dash: -04
Hose Part Hose Pressure Class MPA: 15.0
Hose Part Hose Pressure Class PSI: 2175
Hose Part Hose Pressure Class BAR: 150
Hose Part Hose Standard ISO: Volvo 100
Hose Part Hose Standard SAE: Volvo 100
Hose Part Hose Standard EN: Volvo 100
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Extreme lightness
Hose Part Hose Outer Diameter MM: 12
Hose Part Hose Outer Diameter INCH: 0.47
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 56121/914/400, 56120/914/200, 20076/914/2300, 56126/914/200, 56126/914/500, 56120/914/100, 20077/914/2300, 56126/914/400, 20060/914/2300, 56120/914/300, 56138/914/2300, 20076/916/2500, 20052/914/300, 20489/914/2300
Looking for Part NO.SA9453-02236?
We offer Kobelco / HYUNDAI / Hitachi / Caterpillar / KATO / CASE aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9453-02236 Pilot suitable for 1044532 Servo system, hammer and shear assembly.
Volvo SA9453-02236(c.1044532) Hose assembly
Ref: 1044532 / / 1
VOE8287825(VOE14603834) / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
20460/914/2900
Volvo SA9453-02236 Hose assembly suitable for SE272A Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-02236(c.SE272A) Pilot
Ref: SE272A / / 1
SADH19A001 / U Hydr. leak-off line for hammer-shear. 1 pump
56122/916/1200
Volvo SA9453-02236 Pilot suitable for 1020317 Servo system, hammer and shear assembly.
Volvo SA9453-02236(c.1020317) Hose assembly
Ref: 1020317 / 18 / 1
VOE8280257 / U Switch-controlled function no. 1 for hammer-shear
VOE8280258(VOE14545607) / U Switch-controlled function no. 2 for hammer-shear
VOE8280297 / U / PLUS PARTS SHUTTLE 2 Hydr. leak-off line for hammer-shear.
VOE8280256 / U Switch-controlled function no. 1 for hammer-shear
20076/914/2300
Volvo SA9453-02236 Hose assembly suitable for SD258 Servo system, pump to control valve assembly.
Volvo SA9453-02236(c.SD258) Hose assembly
Ref: SD258 / / 1
SADG00A001 / P / EC290 Basic Machine
56121/914/400
Volvo SA9453-02236 Hose assembly suitable for 1021262 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-02236(c.1021262) Pilot
Ref: 1021262 / 42 / 1
VOE8280255(VOE14545546) / U Hydr. leak-off line for hammer-shear. 2 pump
VOE8280251(VOE14545545) / U Hydr. leak-off line for hammer-shear. 1 pump
20076/916/2500
VOLVO Aftermarket supply Kobelco / Komatsu / Kubota / Doosan / CASE / MITSUBISHI spare parts. MOQ 1 pcs is available! VOLVO Part NO.SA9453-02236 is on sale now!
Part SA9453-02236 suitable for:
VOE8279310(VOE14541478) / U Switch-controlled function no. 2 for hammer-shear
VOE8279308 / U Switch-controlled function no. 1 for hammer-shear
VOE8280258(VOE14545607) / U Switch-controlled function no. 2 for hammer-shear
VOE8280257 / U Switch-controlled function no. 1 for hammer-shear
VOE8292415 / U / ON/OFF 2WAY Switch-controlled function no. 2 for hammer-shear
VOE8278532 / U Switch-controlled function no. 1 for hammer-shear
VOE8278533 / U Switch-controlled function no. 1 for hammer-shear
VOE8278534(VOE14518724) / U Switch-controlled function no. 2 for hammer-shear
Part NO. SA9453-02236 for Volvo EC240B
This catalogue lists the spare parts for Excavator EC240B.
BASIC MACHINE
PROD NO 8277587, EC240B, KOR S/N 10001-12640
PROD NO 8277587, EC240B, CHN S/N 30001-
ENGINE
Part No. : 14500387, D7D EBE2, SER NO 10001-10813
Part No. : 14500387, D7D EBE2, SER NO 10814-
Emission Certificated from EPA
Part No. : 14519201, D7D EEE2, SER NO 10814-
Emission Certificated from EU
Part No. : 14519202, D7D EFE2, SER NO 10814-
Without label
Part NO. SA9453-02236 for Volvo EC140
This catalogue lists the spare parts for Excavator EC140
BUCKETS
Bucket GP. ESCO. 0,32/0,35 - F24
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
0,32 = Volume CECE cubic meter.
0,35 = Volume SAE cubic meter.
S6 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR X 42LCM, 600SR X 46LC
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
42 = Number of track shoes
Part NO. SA9453-02236 for Volvo EC360
This catalogue lists the spare parts for Excavator EC360
BUCKETS
Bucket GP. ESCO. 1,35/1,5 - F24
Description:
GP = General purpose. RB= Rock bucket.
ESCO = Type of bucket tooth, Esco.
1,35 = Volume CECE cubic meter.
1,5 = Volume SAE cubic meter.
S3 = Quick fit bucket.
F24 = Direct-mounted pin-on bucket.
TRACK ASSEMBLY
Track TRK 600SR x 50
Description:
TRK = Track
600 = Width of track
S = Symmetrical track
R = Clearing hole
50 = Number of track shoes
Part NO. SA9453-02236 for Volvo EC240B(SER NO INT 12641- EU & NA 80001-)
This catalogue lists the spare parts for Excavator EC240B.
BASIC MACHINE
PROD NO 8277587, EC240B, SER NO ; KOR 10001- 14193
PROD NO 8277587, EC240B, SER NO ; CHN 30001- 31412
PROD NO 8279625, EC240B, SER NO ; EU and NA 80001 - 81103
PROD NO 8280754, EC240B, SER NO ; INT and KOR 12641 -
ENGINE
Part No. : 14500387, D7D EBE2, SER NO 10814-
Emission Certificated from EPA
Part No. : 14519201, D7D EEE2, SER NO 10814-
Emission Certificated from EU
Part No. : 14519202, D7D EFE2, SER NO 10814-
Without label
Part No. : 14527731, D7E EBE3, SER NO 80001 -
Emission Certificated from EPA/EU
Part NO. SA9453-02236 for Volvo EC360B(PRIME S/N 15001-/85001- 35001-)
This catalog lists the spare parts for Excavator EC360B
BASIC MACHINE
PROD NO 8277279, EC360B, S/N 15001 - 17660 KOR
PROD NO 8277279, EC360B, S/N 85001 - 85181 KOR T3
PROD NO 8277279, EC360B, S/N 35001 - 37598 CHN
ENGINE
Part No. 8188757, D12D-P, 8280231,
S/N 85001 - KOR,
Emission Certificated from EPA and EU
Part No. 8188747, D12D-O, 8280232,
S/N 15001 - KOR,
S/N 35001 - CHN
Part NO. SA9453-02236 for Volvo EW145B
This catalogue lists the spare parts for Excavator EW145B
BASIC MACHINE
PROD NO 8279320, EW145B
ENGINE
Part No. 14524530, D6D EOE2
