Volvo Rockmaster/1SC Part NO. SA9453-03255
Part Name: SA9453-03255 Hose assembly
KDSORT: 270, 210, 200, 190, 480, 400
UE: U
ANT1: 1
ANT2: 1
GLB_ANM1: SER NO 4003-, SER NO 3168-
Hose Recipe Asmoverall Length MM: 2750
Hose Recipe Asmoverall Length Inch: 108.27
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Rockmaster/1SC
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 22.5
Hose Part Hose Pressure Class PSI: 3263
Hose Part Hose Pressure Class BAR: 225
Hose Part Hose Standard ISO: ISO 11237
Hose Part Hose Standard SAE: Volvo 101
Hose Part Hose Standard EN: EN 857 1SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided one layer
Hose Part Hose Remark: Abrasion, weather and heat resistance
Hose Part Hose Outer Diameter MM: 16
Hose Part Hose Outer Diameter INCH: 0.63
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 56117/914/200, 56123/916/1200, 20015/914/300, 20460/914/200, 20498/914/300, 20497/914/300, 20021/914/300, 56141/914/200, 20460/914/210, 20601/914/200
Looking for Part NO.SA9453-03255?
We offer ISUZU / Komatsu / SAMSUNG / Doosan / Hitachi / HYUNDAI spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo SA9453-03255 Hose assembly suitable for 1010057 Servo system, control valve to remote control valve pedal assembly.
Volvo SA9453-03255(c.1010057) Rockmaster/1SC
Ref: 1010057 / 11 / 1
VOE8277784 / P / EC210B Basic Machine
56141/914/200
Volvo SA9453-03255 Hose assembly suitable for SF274 Working hydraulic, hammer and shear for 1st pump flow assembly.
Volvo SA9453-03255(c.SF274) Rockmaster/1SC
Ref: SF274 / / 2
SADJ19A001 / U Hydr. leak-off line for hammer-shear. 1 pump
SADJ19B001 / U Hydr. leak-off line for hammer-shear. 2 pump
56123/916/1200
Volvo SA9453-03255 Rockmaster/1SC suitable for 1010951 Servo system, control valve to solenoid valve assembly.
Volvo SA9453-03255(c.1010951) Rockmaster/1SC
Ref: 1010951 / 39 / 1
VOE8278983 / P / EC180B Basic Machine
VOE8278378 / P / EC160B Basic Machine
20021/914/300, 20498/914/300, 20015/914/300, 20497/914/300
Volvo SA9453-03255 Hose assembly suitable for 1005664 Servo system, control valve to remote control valve pedal assembly.
Volvo SA9453-03255(c.1005664) Hose assembly
Ref: 1005664 / / 1
56117/914/200
Volvo SA9453-03255 Rockmaster/1SC suitable for 1044524 Servo system, control valve to remote control valve pedal assembly.
Volvo SA9453-03255(c.1044524) Hose assembly
Ref: 1044524 / 10 / 1
VOE8290308 / P / EC200B Basic Machine
VOE8289465 / P / 2700 UPPER Basic Machine
VOE8286123 / U / 2700MM Upper frame
20601/914/200, 20460/914/200
Heavy Volvo offer Komatsu / Kobelco / KATO / Hitachi / HYUNDAI / SUMITOMO aftermarket parts. MOQ 1 pcs is available! VOLVO Part NO.SA9453-03255 is on sale now!
Part SA9453-03255 suitable for:
VOE8289465 / P / 2700 UPPER Basic Machine
VOE8286123 / U / 2700MM Upper frame
Part NO. SA9453-03255 for Volvo EC180B
This catalogue lists the spare parts for Excavator EC180B.
BASIC MACHINE
PROD NO 8278983, EC180B
ENGINE
Part No. 14519207, D6D EHE2
Emission Certificated from EU
Part NO. SA9453-03255 for Volvo EC180B(PRIME S/N 12001-)
This catalogue lists the spare parts for Excavator EC180B.
BASIC MACHINE
PROD NO 8278983, EC180B, S/N 12001-
ENGINE
Part No. 14519207, D6D EHE2, Emission Certificated from EU
Part NO. SA9453-03255 for Volvo EC160B
This catalogue lists the spare parts for Excavator EC160B.
BASIC MACHINE
PROD NO 8278378, EC160B
ENGINE
Part No. 14514721, D6D EBE2, SER NO 10001-10079
Part No. 14514721, D6D EBE2, SER NO 10080-
Emission Certificated from EPA
Part No. 14519207, D6D EHE2, SER NO 10080-
Emission Certificated from EU
Part No. 14519208, D6D EIE2, SER NO 10080-
Without label
Part NO. SA9453-03255 for Volvo EC200B(PRIME S/N 30001-31313)
This catalogue lists the spare parts for Excavator EC200B.
BASIC MACHINE
PROD NO 8290308, EC200B, CHN S/N 30001 - 31313
ENGINE
Part No. 14536073, D6D, Without label
Part NO. SA9453-03255 for Volvo EC160B(PRIME S/N 12001-)
This catalogue lists the spare parts for Excavator EC160B.
BASIC MACHINE
PROD NO 8278378, EC160B, S/N 12001-
ENGINE
Part No. 14514721, D6D EBE2, Emission Certificated from EPA
Part No. 14519207, D6D EHE2, Emission Certificated from EU
Part No. 14519208, D6D EIE2, Without label
Part NO. SA9453-03255 for Volvo EC460
EXCAVATOR VOLVO EC460
BASIC MACHINE
PROD NO DJ00A001 EC460
ENGINE
Part No. 1111-00791 Typ, MTA11-C
Part No. 1111-00841 Typ, LTA10-C for tropics
