Volvo EC380D(S/N 21/23/231/26 270001-, 280001-) Eternity/2 Part NO. VOE936243
Part Name: VOE936243 Hose assembly
KDSORT: 350, 460, 280, 480, 500, 230
UE: U
ANT1: 1
ANT2: 1
GLB_ANM1: S/N -271448, -280413,, S/N 271356-271448, S/N -271337, S/N 310605-, S/N 310248-
GLB_ANM2: S/N 271450, S/N 280356-280413, S/N -280355
GLB_ANM3: S/N 271450
Hose Recipe Asmoverall Length MM: 650
Hose Recipe Asmoverall Length Inch: 25.59
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 36.5
Hose Part Hose Pressure Class PSI: 5293
Hose Part Hose Pressure Class BAR: 365
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 17
Hose Part Hose Outer Diameter INCH: 0.67
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20593/924/200, 20656/924/200, 20592/924/200, 20715/924/510, 20687/924/210
Looking for Part NO.VOE936243?
We offer Komatsu / Hitachi / SAMSUNG / Caterpillar / CASE / SUMITOMO spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE936243 Hose assembly suitable for 1065640 Working hydraulic, quick fit on upper frame assembly.
Volvo VOE936243(c.1065640) Hose assembly
Ref: 1065640 / 14 / 2
VOE8292511 / U Quick fit piping
VOE8292510 / U Quick fit piping
20656/924/200
Volvo VOE936243 Hose assembly suitable for 1058007 Working hydraulic, quick fit on upper frame assembly.
Volvo VOE936243(c.1058007) Eternity/2
Ref: 1058007 / 14 / 2
VOE8289178(VOE14626175) / U Hydr. Quick fit equipment on basic machine
VOE8290705 / U / UQF36 Hydr. Quick fit equipment on basic machine
VOE8289179(VOE14626176) / U / UQF Hydr. Quick fit equipment on basic machine
20593/924/200, 20592/924/200
Volvo VOE936243 Eternity/2 suitable for 1091798 Working hydraulic, quick fit on upper frame assembly.
Volvo VOE936243(c.1091798) Eternity/2
Ref: 1091798 / / 1
VOE8293337(VOE14673164) / U / UQF Hydr. Quick fit equipment on basic machine
20687/924/210, 20715/924/510
We supply HYUNDAI / CASE / Hitachi / Caterpillar / Komatsu / KATO spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE936243 is on sale now!
Part NO. VOE936243 for Volvo EC380DHR(HIGH REACH DEMOLITION S/N 290011-290020,291001-)
EXCAVATOR VOLVO EC380D HR
BASIC MACHINE
PROD NO. 8292497 S/N 290001- 290020
CAB
PROD NO. 8292276
PROD NO. 8292275
ENGINE
D13H-D, EU
Product No. 15117871
Replacement version 15173113
D13H-C, US
Product No. 15049436
Replacement version 15173113
Part NO. VOE936243 for Volvo EC380E(S/N 310001-)
EXCAVATOR VOLVO EC380E
BASIC MACHINE
Product no. 8293277, S/N 310001-
CAB
Product no. 8293303
Product no. 8293304
Product no. 8295011
Product no. 8295012
Product no. 8295391
Product no. 8302183
Product no. 8302044
Product no. 8302046
Product no. 8302050
Product no. 8302052
ENGINE
Product no. 15185568
Replacement version 17272079
Product no. 15185569
Replacement version 17272080
Product no. 17481129
Replacement version 17481323
Product no. 17479201
Replacement version 17510356
Product no. 17479200
Replacement version 17510359
Part NO. VOE936243 for Volvo EC350E(S/N 310001-)
EXCAVATOR VOLVO EC350E
BASIC MACHINE
Product number 8296122, Serial number 310001-
CAB
Product number 8293303
Product number 8293304
Product number 8295011
Product number 8295012
Product number 8302044
Product number 8302046
Product number 8302050
Product number 8302052
ENGINE
Product number 15185569
Replacement version 17272080
Product number 17481129
Replacement version 17481323
Product number 17479201
Replacement version 17510356
Part NO. VOE936243 for Volvo EC380D(S/N 21/23/231/26 270001-, 280001-)
EXCAVATOR VOLVO EC380D
BASIC MACHINE
Product number 8289022, Serial number 210001-210684, 230001-230821, 231001-, 260001-260037, 270001-, 280001-
SUB BASIC MACHINE
Product number 8291893, Serial number 210112-
Product number 8291894, Serial number 230001-, 231001-, 260001-260037, 270001-, 280001-
Product number 8291539, Demolition, Serial number 210112-
Product number 8301352, Serial number 271596-, 280598-, 231138-
Product number 8301351, Serial number 271596-, 280598-, 231138-
CAB
PART NO. 11294089, 11294090
ENGINE
PART NO. 15117871, 13L, EU, 8289023
part not stocked as spare part
PART NO. 15049436, 13L, US, 8289891
part not stocked as spare part
PART NO. 15173113, replacement version
PART NO. 15049434, 13L, 8290569
part not stocked as spare part
PART NO. 17216261, replacement version
PART NO. 15049435, 13L, 8290568
part not stocked as spare part
PART NO. 17216264, replacement version
Part NO. VOE936243 for Volvo EC340D(S/N 210001-210482)
EXCAVATOR VOLVO EC340D
BASIC MACHINE
PROD NO. 8289415 , S/N 210001 - 210479
SUB BASIC MACHINE
PROD NO. 8290856, S/N 210016 - 210479
PROD NO. 8290857, S/N 210016 - 210479, Waste handler
CAB
PART NO. 11294089, 11294090
ENGINE
PART NO. 15117871, D13H-D STP4A, EU/US, 8289023
part not stocked as spare part
PART NO. 15049436, D13H-C STP4A, NA, 8289891
part not stocked as spare part
PART NO. 15173113, replacement version
