Volvo ECR145C(S/N 110001-) VOE936357 Hose assembly wholesale
Part Name: VOE936357 Hose assembly
KDSORT: 340, 260, 210, 180, 400, 170, 110, 100, 160
UE: U
ANT1: 1
ANT2: 1
Hose Recipe Asmoverall Length MM: 800
Hose Recipe Asmoverall Length Inch: 31.50
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Xtraflex/5000
Hose Part Hose Size DN: 19
Hose Part Hose Size Inch: 3/4"
Hose Part Hose Dash: -12
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 18752-C
Hose Part Hose Standard SAE: Volvo 106
Hose Part Hose Standard EN: Volvo 106
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Extreme flexibility
Hose Part Hose Outer Diameter MM: 32
Hose Part Hose Outer Diameter INCH: 1.26
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20490/916/2250, 20079/916/2600, 20136/916/2600, 20726/916/2600, 20098/916/2600, 20460/911/450, 20490/916/2200, 20865/911/450, 20641/911/400, 20641/911/1600, 20463/911/1900, 20138/911/400, 20763/911/1000, 20079/916/2610
Looking for Part NO.VOE936357?
We offer HYUNDAI / YANMAR / CASE / Hitachi / Doosan / CUMMINS spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE936357 Xtraflex/5000 suitable for 1045709 Hydraulic system, control valve to boom and swing assembly.
Volvo VOE936357(c.1045709) Xtraflex/5000
Ref: 1045709 / 9 / 1
VOE8289338 / U Float position for boom
20460/911/450
Volvo VOE936357 Hose assembly suitable for 1039616 Working hydraulic, hammer and shear for 2nd pump flow assembly.
Volvo VOE936357(c.1039616) Xtraflex/5000
Ref: 1039616 / 1 / 1
VOE8277680(VOE14515933) / U Hydr. leak-off line for hammer-shear. 2 pump
20079/916/2600
Volvo VOE936357 Xtraflex/5000 suitable for 1094307 Hydraulic system, return lines assembly.
Volvo VOE936357(c.1094307) Xtraflex/5000
Ref: 1094307 / 2 / 1
VOE8299896 / U / SOFT SWING Swing function
20865/911/450, 20866/911/450
Volvo VOE936357 Hose assembly suitable for 1022782 Working hydraulic, hammer and shear for 2nd pump flow assembly.
Volvo VOE936357(c.1022782) Hose assembly
Ref: 1022782 / 31 / 1
VOE8281103(VOE14564071) / U Hydr. leak-off line for hammer-shear. 2 pump
20098/916/2600
Volvo VOE936357 Xtraflex/5000 suitable for 1029496 Working hydraulic, hammer and shear for 2nd pump flow assembly.
Volvo VOE936357(c.1029496) Xtraflex/5000
Ref: 1029496 / 25 / 1
VOE8289491 / U / X1,2WAY CONTROL Switch-controlled function no. 2 for hammer-shear
VOE8286141(VOE14603851) / U Hydr. leak-off line for hammer-shear. 2 pump
VOE8297154 / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 2 pump
20460/911/1600, 20763/911/1000
We supply CASE / Kubota / Kobelco / HYUNDAI / Deutz / YANMAR spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE936357 is on sale now!
Part VOE936357 suitable for:
VOE8277980(VOE14515927) / U Hydr. leak-off line for hammer-shear. 1 pump
VOE8277982(VOE14515935) / U Hydr. leak-off line for hammer-shear. 2 pump
VOE8279197 / U / SINGLE ACTING Hydr. leak-off line for hammer-shear. 1 pump
VOE8284207 / U / 2 WAY LONG LOADER RB Pedal-controlled function for hammer-shear
VOE8294496 / U / DOUBLE ACTING Hydr. leak-off line for hammer-shear. 2 pump
VOE8279644(VOE14546731) / U Hydr. leak-off line for hammer-shear. 2 pump
Part NO. VOE936357 for Volvo EC240B(PRIME S/N 15001-16436/ 40001-40237/ 35001-37526)
This catalogue lists the spare parts for Excavator EC240B.
BASIC MACHINE
PROD NO 8277587, EC240B, SER NO ; KOR 15001- 16436
PROD NO 8277587, EC240B, SER NO ; CHN 35001- 37526
PROD NO 8277587, EC240B, SER NO ; BRA 040001- 40237
ENGINE
Part No. : 14536074, D7E EBE2, Without label
Part NO. VOE936357 for Volvo EC140B(PRIME S/N 15001-, 30001-30121, 40001-)
This catalogue lists the spare parts for Excavator EC140B.
BASIC MACHINE
PROD NO 8277787, EC140B, S/N 15001-, 30001-30121, 40001-40976
ENGINE
Part No. 14521396, D4D EAE2, Emission Certificated from EPA
Part No. 14521397, D4D EBE2, Emission Certificated from EU
Part No. 14521398, D4D ECE2, Without label
Part NO. VOE936357 for Volvo EC210B(PRIME S/N 35-,40-,50-, 70-,80-,81-,90-,95-95057)
This catalogue lists the spare parts for Excavator EC210B.
BASIC MACHINE
PROD NO 8277784, EC210B, CHN S/N 35001 - 39999
PROD NO 8277784, EC210B, CHN S/N 90001 - 92051
PROD NO 8277784, EC210B, CHN S/N 95001 - 95057
PROD NO 8277784, EC210B, BRA S/N 40001 - 41093
PROD NO 8277784, EC210B, IND S/N 50001 - 52370
PROD NO 8277784, EC210B, KOR S/N 70001 - 79999
PROD NO 8277784, EC210B, KOR S/N 80001 - 80188
PROD NO 8277784, EC210B, KOR S/N 81001 -
ENGINE
Part No. 14536076, D6E EAE3, Emission Certificated from EPA and EU
Part No. 14536073, D6E EAE2, Without label
Part NO. VOE936357 for Volvo EC210D(S/N 230001-, 280001- S/N 250001-)
EXCAVATOR VOLVO EC210D
BASIC MACHINE
PROD NO. 8297134, S/N 230001-, 250001-, 280001-
SUB BASIC MACHINE
Product number 8301443, Serial number 281134-, 250138-, 230230-
CAB
PROD NO. 8296864
ENGINE
PART NO. 17387726, D5 T3
Part NO. VOE936357 for Volvo EC240C
This catalogue lists the spare parts for Excavator EC240C.
BASIC MACHINE
PROD NO 8281075, EC240C, KOR SER NO ; 110001 - 111049
PROD NO 8281075, EC240C, KONZ SER NO ; 120001 - 120675
PROD NO 8281075, EC240C, USA SER NO ; 140001 - 140019
ENGINE
Part No. : 14527731, D7E EBE3 Emission Certified from EPA/EU
Part NO. VOE936357 for Volvo ECR145D(S/N 210001-210766)
EXCAVATOR VOLVO ECR145D
BASIC MACHINE
PROD NO. 8290284, S/N 210001- 210766
CAB
PART NO. 8290225, 8291326
ENGINE
PART NO. 15165683, D4, EU
part not stocked as spare part
PART NO. 17231751, replacement version
PART NO. 15083702, D4, US
part not stocked as spare part
PART NO. 17231719, replacement version
