Volvo ECR28(TYPE 601) Hose assembly Part NO. VOE11803526
Part Name: VOE11803526 Hose assembly
KDSORT: 340, 120
UE: U
ANT1: 1
GLB_ANM1: L = 1025mm/40.3543in
Hose Recipe Asmoverall Length MM: 1025
Hose Recipe Asmoverall Length Inch: 40.35
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 2
Hose Recipe Status: A
Hose Recipe Protector Length MM: 963
Hose Recipe Protector Length INCH: 37.91
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 10
Hose Part Hose Size Inch: 3/8"
Hose Part Hose Dash: -06
Hose Part Hose Pressure Class MPA: 36.5
Hose Part Hose Pressure Class PSI: 5293
Hose Part Hose Pressure Class BAR: 365
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 17
Hose Part Hose Outer Diameter INCH: 0.67
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20132/916/450, 20047/916/3000
Looking for Part NO.VOE11803526?
We supply YANMAR / HYUNDAI / ISUZU / Doosan / Kobelco / KATO spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
Volvo VOE11803526 Eternity/2 suitable for 1074969 Working hydraulic, dipper arm assembly.
Volvo VOE11803526(c.1074969) Eternity/2
Ref: 1074969 / 2 / 1
VOE11839819 / U / SHORT ARM Hydraulic circuit for breaker and clamshell
VOE11839820 / U / LONG ARM Hydraulic circuit for breaker and clamshell
20132/916/450
Volvo VOE11803526 Eternity/2 suitable for 1074960 Hydr. circuit. ( attachment ) ( grab jaw ) assembly.
Volvo VOE11803526(c.1074960) Eternity/2
Ref: 1074960 / 19 / 1
20047/916/3000
We supply CUMMINS / Deutz / SAMSUNG / Caterpillar / Hitachi / Komatsu spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE11803526 is on sale now!
Part NO. VOE11803526 for Volvo EC27C
EXCAVATOR VOLVO EC27C
BASIC MACHINE
PROD NO 11839907
S/N 2742 - 5457
ENGINE
Part No. 11806934, Type 3TNV88-BSVE
Part NO. VOE11803526 for Volvo ECR28(TYPE 601)
EXCAVATOR VOLVO ECR28
BASIC MACHINE
601.10151 ECR28
ENGINE
Part No. VOE 11801174 Typ, D1.2A, S/N - 11410
Part No. VOE 15614793 Typ, D1,1DCBE4, S/N 11411 -
