Volvo L30B(S/N - 1803869/1812999/ 1822999) ZM2120880 Eternity/2 wholesale
Part Name: ZM2120880 Hose assembly
KDSORT: 250, 8051, 150, 490, 450, 143, 8046, 410, 520, 400, 690, 240, 8042, 500
UE: U
ANT1: 2, 4, 1
ANT2: 2, 4, 1
ANT3: 2, 4, 1
ANT4: 2
INFLYTT: 1
GLB_ANM1: 1800 MM, 1650 mm
Hose Recipe Asmoverall Length MM: 760
Hose Recipe Asmoverall Length Inch: 29.92
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 1
Hose Recipe Status: A
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Eternity/2
Hose Part Hose Size DN: 12
Hose Part Hose Size Inch: 1/2"
Hose Part Hose Dash: -08
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 11237 2SC
Hose Part Hose Standard SAE: SAE 100R16
Hose Part Hose Standard EN: EN 857 2SC
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire braided two layer
Hose Part Hose Remark: High service life and reliability
Hose Part Hose Outer Diameter MM: 21
Hose Part Hose Outer Diameter INCH: 0.83
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20038/925/400, 20650/925/6620, 07503/92544/100, 20650/925/6400, 20650/925/6630, 07517/92545/200, 20042/925/500, 07518/92633/100, 20040/911/200, 07514/92543/100, 07517/92633/100, 07502/92633/100, 20041/925/500, 07518/92545/200
Looking for Part NO.ZM2120880(VOE11305118)?
We supply YANMAR / KATO / ISUZU / Caterpillar / Deutz / HYUNDAI spare parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE11305118 replacement for new Part NO.ZM2120880
Volvo ZM2120880 Hose assembly suitable for 00000284 Hydraulic lines - tilt hydraulic assembly.
Volvo ZM2120880(c.00000284) Eternity/2
Ref: 00000284 / 6 / 2
07518/91121/200, 07502/91121/200
Volvo ZM2120880 Hose assembly suitable for 00000358 Combined bucket - Tpv assembly.
Volvo ZM2120880(c.00000358) Hose assembly
Ref: 00000358 / 53 / 4
07503/92544/100, 07512/92544/100
Volvo ZM2120880 Eternity/2 suitable for 1057196 Multi-purpose bucket assembly.
Volvo ZM2120880(c.1057196) Hose assembly
Ref: 1057196 / 30 / 2
VOE11391106 / U / 1800 MM Multi-purpose bucket
VOE11391094 / U / 1650 MM Multi-purpose bucket
VOE11391092 / U / 1800 MM Multi-purpose bucket
20579/92542/400
Volvo ZM2120880 Eternity/2 suitable for 1070637 Multi-purpose bucket assembly.
Volvo ZM2120880(c.1070637) Eternity/2
Ref: 1070637 / 28 / 2
VOE11391141 / U / Z, 0,9 M3,1900 MM Multi-purpose bucket
VOE11391229 / U / Z, 1,0 M3,2000 MM Multi-purpose bucket
VOE11391143 / U / Z, 0,8 M3,1900 MM Multi-purpose bucket
20650/925/6430, 20650/925/6440, 20650/925/6420
Volvo ZM2120880 Eternity/2 suitable for 1070652 Multi-purpose bucket assembly.
Volvo ZM2120880(c.1070652) Eternity/2
Ref: 1070652 / 30 / 2
VOE11391631 / U / Z, 1,1 M3, 2000 MM, VTS, SPECIAL Multi-purpose bucket
20650/925/6480
VOLVO Construction parts offer HYUNDAI / Hitachi / Komatsu / Kobelco / Caterpillar / SAMSUNG spare parts. MOQ 1 pcs is available! VOLVO Part NO.ZM2120880(VOE11305118) is on sale now!
Part NO. ZM2120880 for Volvo L45B(S/N 1941500 - S/N 1951500 -)
WHEEL LOADER VOLVO L45B
BASIC MACHINE
2892240, L45B, SER. NO. 1941500 - 1943000
2892235, L45B, SER. NO. 1951500 - 1953000
2892240, L45B, SER. NO. 1943001 -
2892235, L45B, SER. NO. 1953001 -
CAB
2812296 Laminated safety glass
2812295 Single layer safety glass toughened glass
2812174 Canopy
ENGINE
11306245, Volvo D5DCBE2, Basic machine Ser.no. 1941500-
11306393, Volvo D5DCBE2, Basic machine Ser.no. 1951500-
15202334, Volvo D5DCGE3, Basic machine Ser.no. 1943001-
15202333, Volvo D5DCGE3, Basic machine Ser.no. 1953001-
FRONT AXLE
2813984, Basic machine Ser.no. 1941500-
2813983, Basic machine Ser.no. 1951500-
REAR AXLE
2813986, Basic machine Ser.no. 1941500-
2808622, Basic machine Ser.no. 1951500-
TRANSMISSION
2906472, Basic machine Ser.no. 1941500-
2906474, Basic machine Ser.no. 1951500-
Part NO. ZM2120880 for Volvo L45(TYPE 194, 195 SER NO - 1000)
WHEEL LOADER VOLVO L45
BASIC MACHINE
2892240, SER NO. 1940001-
2892235, SER NO. 1950001-
CAB
2812296 Laminated safety glass
2812295 Single layer safety glass toughened glass
2812174 Canopy
ENGINE
2810935, Basic machine Ser.no 1940001-
2810934, Basic machine Ser.no 1950001-
FRONT AXLE
2808627, Basic machine Ser.no 1940001-
2808614, Basic machine Ser.no 1950001-
REAR AXLE
2808629, Basic machine Ser.no 1940001-
2808622, Basic machine Ser.no 1950001-
TRANSMISSION
2906472, Basic machine Ser.no 1940001-
2906474, Basic machine Ser.no 1950001-
Part NO. ZM2120880 for Volvo L30B(S/N - 1803869/1812999/ 1822999)
WHEEL LOADER VOLVO L30B
BASIC MACHINE
2892224, SER NO. 1802201 - 1803869
2892226, SER NO. 1812201 - 1812999
2892227, SER NO. 1822201 - 1822999
CAB
2812267 Laminated safety glass
2812266 Single layer safety glass toughened glass
2812168 Canopy
ENGINE
2814007
2814010 USA
FRONT AXLE
2808619, Basic machine ser.no. 1802201 - 1803869
2808618, Basic machien ser.no. 1812201 - 1812999
2808618, Basic machine ser.no. 1822201 - 1822999
REAR AXLE
2808620, Basic machine ser.no. 1802201 - 1803869
2808621, Basic machine ser.no. 1812201 - 1812999
2816424, Basic machine ser.no. 1822201 - 1822999
Part NO. ZM2120880 for Volvo L30B(TYPE 182, 183, 185 SER NO 3000 -)
WHEEL LOADER VOLVO L30B
BASIC MACHINE
2892227, L30B, S/N 1823000-
2892225, L30B, S/N 1833000-
11390010, L30B, S/N 1853000-
2892227, L30B, S/N 1826001-
2892225, L30B, S/N 1836001-
11390010, L30B, S/N 1856001-
CAB
2812267 Laminated safety glass
2812266 Single layer safety glass toughened glass
2812168 Canopy
ENGINE
11306227, Volvo D3DCDE2, S/N 1823000-1823649, 1833000-1833786, 1853000-1854771
11309553, Volvo D3DCDE2, S/N 1823650-1826000, 1833787-1836000, 1854772-1856000
11308623, Volvo D3DCCE3, S/N 1826001-1826026, 1836001-1836201, 1856001-1857450
15211727, Volvo D3,6DCCE3, S/N 1826018, 1836112, 1856785
15216363, Volvo D3,6DCCE3, S/N 1826027-, 1836202-, 1857451-
FRONT AXLE
2808618, S/N 1823000-1823600 / 1833000-1833600
2808619, S/N 1853000-1853600
11306792, S/N 1823601- / 1833601-
11306793, S/N 1853601-
REAR AXLE
2816424, S/N 1823000-1823600
2808621, S/N 1833000-1833600
2808620, S/N 1853000-1853600
11307406, S/N 1823601-
11306795, S/N 1833601-
11306794, S/N 1853601-
Transmission
2906359, S/N 1823000-1823600 / 1853000-1853600
2906360, S/N 1833000-1833600
11715060, S/N 1823601- / 1853601-
11715061, S/N 1833601-
Part NO. ZM2120880 for Volvo L40(TYPE 191, 192 SER NO - 1000)
WHEEL LOADER VOLVO L40
BASIC MACHINE
2892236, SER NO. 1910001-
2892233, SER NO. 1920001-
CAB
2812296 Laminated safety glass
2812295 Single layer safety glass toughened glass
2812174 Canopy
ENGINE
2810933, Basic machine Ser.no 1910001-
2810932, Basic machine Ser.no 1920001-
FRONT AXLE
2808627, Basic machine ser.no 1910001-
2808614, Basic machien ser.no 1920001-
REAR AXLE
2808628, Basic machine ser.no 1910001-
2808626, Basic machine ser.no 1920001-
TRANSMISSION
2906471, Basic machine Ser.no 1910001-
2906473, Basic machine Ser.no 1920001-
Part NO. ZM2120880 for Volvo L20B(TYPE 170, S/N 0500 - TYPE 170, S/N 3001 -)
WHEEL LOADER VOLVO L20B
BASIC MACHINE
11390000, L20B, S/N 1700500 - 1705000
11390000, L20B, S/N 1703001 - 1705000
CAB
11305124, Cab L20 - L25
ENGINE
11306225 Volvo D3D CAE2
11308621 Volvo D3.6D CAE3
15211725 Volvo D3,6D CAE3
FRONT AXLE
2813987, ZF - AP-R715
15200436
REAR AXLE
2813988, ZF - AP-R715
15200437
